1.2 Product reference structure All-plastic cable ties Example: Tie Dimension Code TY X X X X TY 18 X 100 100 Additional code for Tie Width / Colour / Material packaging Tie Length Code Tensile Strength Code Standard cable for lengths 18 = 2.4 mm / (80N) All product references are made Blank = ties with a from 91 mm 40 = 3.6 mm / (180N) of halogen free Polyamide 6.6, Bulk packaging (1000 / width up to up to 50 = 4.6 mm / (220N) UL 94 V-2, operating 500 / 50 ties according 13.2 mm 1214 mm 120 = 7.6 mm / (540N) temperature -40C to +85C to the size of the tie) 175 = 8.8 mm / (780N) blank = natural 250 = 13.2 mm / (1120N) X = black, UV-stabilized 50 = 50 ties in a bag 1 = brown with Euroslot 2 = red (only for Prod. Ref. 3 = orange TY400-120) 4 = yellow 5 = green 100 = 100 ties in a bag 6 = blue with Euroslot (not 7 = purple available for Prod. Ref. 8 = grey TY400-120 & TY800- 9 = white 120) 20 = black 39 = Heat stabilised, temperature range: -40C to +105C, natural * X = outdoor use, UV-stabilised, (UL 94 HB for TY...-120X range), 48 black Note: Nylon (Polyamide) is inherently susceptible to environmental conditions. Ty-Fast cable ties are moisturised to optimum performance levels at machine- side and should be stored in cool dry areas out of direct sunlight. Cable ties are packaged in plastic bags to contain moisture and should remain sealed until ready for use. Thomas & Betts www.tnb-europe.com1.2 Standard cable ties All-plastic cable ties State-of-the-art robotic and raw material handling equipment assures product and material integrity throughout the manufacturing process. The integrally formed Polyamide pawl combines low insertion and high locking strength A rounded, low-profile head makes for less snags Tails have improved two-sided finger grip design that helps the operator grasp and pull ties snug Sure Grip tab keeps the tail from popping out while being threaded, then holds it securely for final tightening by hand or tool Quick and easy pull through increases productivity, reduces opera- tor fatigue Technical Information ** ** ** ** Material Polyamide 6.6 (*) TYPETYPE E49405 AAPPPPROVROV EEDD Temperature range -40C to +85C Colour Natural as standard colour (*) Approvals MIL: MS 3367-x (see table) Flammability rating UL 94 V-2 Other properties Halogen free, Silicone free (*) For other materials and colours see the product reference structure page 48 Product Ref. MIL Spec. Length Width Bundle diameter Minimum tensile Quantity Tooling LW from ... to strength mm mm mm N pieces TY075-18 MS-3367-4 91 2.4 1.6 - 20 80 1000 TY100-18 112 2.4 1.6 - 25 80 1000 TY125-18 136 2.4 1.6 - 32 80 1000 TY200-18 203 2.4 1.6 - 50 80 1000 ERG50 TY125-40 MS-3367-5 141 3.5 1.6 - 32 180 1000 WT193A TY200-40 205 3.5 1.6 - 50 180 1000 TY300-40 290 3.5 1.6 - 76 180 1000 TY400-40 368 3.5 1.6 - 102 180 1000 TY175-50 MS-3367-1 186 4.6 1.6 - 44 220 1000 ERG50 TY225-50 226 4.6 1.6 - 57 220 1000 ERG120 TY300-50 291 4.6 1.6 - 76 220 1000 WT193A TY400-50 MS-3367-2 366 4.6 1.6 - 102 220 1000 TY200-120 219 7.6 4.8 - 50 540 500 ERG120 TY400-120 MS-3367-3 375 7.6 4.8 - 102 540 500 L-500-EU TY800-120 706 7.6 4.8 - 203 540 50 WT3D ** Some approvals may not be applicable to all the Product References. Contact your Sales office for approvals limitations Description of Product Reference structure: see page 48 Description of materials and properties: see pages 134 to 145 For tooling specifications: see pages 122 to 133 49 Thomas & Betts www.tnb-europe.com
