RF18
Universal wireless remote control
A
systems with receivers
Technical specifications
Remote control One-way Two-way
version version
Frequency 433.92MHz 869.525MHz
Radiated RF power 1mW 6mW
Temperature range -30/+70C -30/+70C
Modulation ASK FSK
Number of keys 1, 2, 4 and 8 keys 1, 2, 3 and 4 keys
OEM receiver -
The ARF18 long range remote controls enable wireless control
asynchronous link
of 1 to 24 digital states over a distance of 300m.
Power supply (Vcc) 3.3V nominal 2.7 to 3.6V nominal
Consumption in receipt 15mA 15mA
ARF18 Sensitivity -104dBm -104dBm
These remote controls are available in one-way or two-way versions (433
Serial interface level 0/VCC Serial interface level 0/VCC
Outputs
4 binary outputs 4 binary outputs
or 868MHz) and are approved according to the European directive RTTE EN
1, 2 or 4 relays
300-220/EN 301-489.
receiver
Power supply 15 to 30 VDC
Security of transmission is ensured by means of a proprietary rotating code
Consumption 30mA open relays
and a unique serial number.
(130mA closed)
They are associated with a complete range of 1, 2 or 4 relays receivers, OEM
Switching capacity 230VAC max 10A
receivers, serial decoder (RS232 or USB).
Relays * 1 relay: 1NO/NC
* 2 relays: 1NO + 1NO/NC
In the two-way version, the command acknowledgement provides a maximum * 4 relays: 3NO + 1NO/NC
level of security for applications involving access control, alarms...
Serial decoder
Serial ports RS232 or USB
More generally, these products cover multiple applications from simple
Format 8 bits, no parity, 1 stop
Con guration through
domestic remote control to autonomous control of tertiary or industrial
AT commands
equipment, in sectors of activity such as home automation, systems
Serial link rate 2.4 to 115.2kBps
automation, industrial automation...
Power supply 8 to 30VDC
Starter-Kits
Integration kit for: * 1 demoboard including * 1 demoboard including
Part numbers
* Evaluate the products 1 mother board with 1 mother board with
One-way version Two-way version * Perform RF 1 soldered OEM RF module 1 soldered OEM RF module
measurements * 1 remote control * 1 remote control
Remote control ARF7291X* ARF7292X**
* Develop a prototype * 1 whip antenna * 1 whip antenna
OEM receiver ARF7293A ARF7294A
* 1 RS232 cable * 1 RS232 cable
ARF7341F
1 relay receiver - IP65 box
2 relays receiver - IP65 box ARF7341D
4 relays receiver - IP65 box ARF7341B
RS232 serial decoder - IP65 box ARF7263K
ARF7263S
USB serial decoder - IP65 box
Starter-Kits ARF7439S ARF7439M
*X = index A/B/D/R = 1/2/4/8 keys
**X = index A/B/C/D = 1/2/3/4 keys
283 rue Louis Nel - Parc technologique Pr Roux - 38920 CROLLES - France
Sales department: +33 (0)4 76 92 07 77 - Fax : +33 (0)4 76 04 80 87 - E-mail : arf@adeunis-rf.com - www.adeunis-rf.com
