Part No.	AM1DS-1505SJZ
Manufacturer:	Aimtec
Category:	Isolated DC/DC Converters
Description:	Converter: DC/DC; 1W; Uin: 13.5÷16.5V; Uout: 5VDC; Iout: 200mA; SIP7
Datasheet:	AM1DS-1505SJZ Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 3.6377 ea
Line Total: USD 3.64

Availability - 13
Ship by Fri. 29 Nov to Tue. 03 Dec

MOQ: 1 Multiples: 1
Pack Size: 1

AM1DS-1505SJZ More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

13

Ship by Fri. 29 Nov to Tue. 03 Dec

MOQ : 1
Multiples : 1

1 : USD 3.6377
5 : USD 3.528
25 : USD 3.4496
50 : USD 3.4026

Specifications

Manufacturer
Aimtec Aimtec

Product Category
Isolated DC/DC Converters Isolated DC/DC Converters

Category
Isolated DC/DC Converters Isolated DC/DC Converters

Mounting
THT THT

Power
1 W 1 W

Output Current
200 mA 200 mA

Output Voltage
5 VDC 5 VDC

Protection
short circuit protection SCP short circuit protection SCP

Weight
2.1 g 2.1 g

Insulation Voltage
1500 VDC 1500 VDC

Case
SIP7 SIP7

Input Voltage
13.5 To 16.5 V 13.5 To 16.5 V

Manufacturer Series
AM1DS - JZ AM1DS - JZ

Operating Temperature
- 40 To 105 C - 40 To 105 C

Efficiency
80 % 80 %

Type Of Converter
DC/DC DC/DC

Body Dimensions
19.65x6x10.16mm 19.65x6x10.16mm

Notes:- Show Stocked Products With Similar Attributes.
