PowerTe PowerTecctor Series PowerTecttoor Series r Series Low Voltage Discon Low Voltage Disconnnect Low Voltage Disconneecct t Solid State Battery Guard Fully Programmable The PowerTector Battery Guard is a solid state device that will monitor the source All units in the range are supplied voltage and disconnect the equipment from the battery if the voltage falls below a pre-programmed for a variety of pre-determined level. This can work to ensure that there is always sufficient voltage scenarios offering higher or lower remaining in the battery to start a vehicle engine or ensure power is available for disconnect voltages to and it is quick other critical applications. The total discharge of a lead acid battery can also cause and simple to select the correct damage to the cells significantly shortening the life of the battery, so the PowerTector programme to suit your needs unit can also be set to disconnect equipment at a lower voltage that will still protect whether it is to avoid battery damage the battery from total discharge, while allowing for maximum battery usage. due or to protect key equipment. A Wide Range and a Using the simple programming terminal, select the pre-set IP65 Multitude of Features disconnect voltage according to your requirements. There are six units in the range from 10A to 200A. The 10A and 20A unit LED indicates offer a simple inline system, usually operational status. wired to a specific piece of equipment. These units do not Audible alarm and/or require chassis mounting and simply Visual indicator can be connect and tie wrap neatly within the installed in the dashboard or cockpit to alert operator wiring system. of a potential problem The 40A and 60A units are connected by M6 brass bolts and use a three Switch terminal allows the unit point mounting system to avoid All PowerTectors to be operated via the ignition or a from 40A upwards are mounted rocking or stress to the electronics manual switch in a rugged die cast aluminium casing when mounted on uneven surfaces. with glass filled polycarbonate cover Heat is dissipated into our custom providing terminal protection and insulation. Manual Shutdown Facility manufactured die cast casing and all units will operate at full power without From 40A upwards, the units also offer additional heatsinking dissipation. the facility to fit a switched cable to The terminals are insulated from each allow the unit to be connected directly to the ignition or switch. In addition, the other using a solid polycarbonate top The assembly that provides physical 100A and 200A units can have a PowerTector manual override switch. This ensures protection to avoid accidental short Battery Guards offer excellent circuit or unintentional current bypass that the operator investigates the protection for reason for disconnection prior to and also houses the programming communication terminal. A multifunction LED resetting the device to allow emergency and other actions to be performed. provides both programming and mission critical applications status information and a connection is IP65 Protection also available to run a wire through to the cockpit or dashboard where visual All units are protected to IP65, so are and audible indicators such as lights fully waterproof, using ultra high and buzzers can be attached to alert performance flexible compound that the user of a potential problem. allows for the natural expansion and contraction of the electronics without the danger of component fracture characteristic of many hard epoxy based resins which can cause long term failure. The extended life offered by this method allows Alfatronix to offer Alfatronix Limited, 29 Newtown Business Park, Poole, Dorset, BH12 3LL, England Telephone: +44 (0)1202 715517. Fax: +44 (0)1202 715122 our full lifetime guarantee. Website: www.alfatronix.com E mail: sales alfatronix.com An ISO9001:2000 Registered Company Conversion Automotive, Communications Marine Applic Poweerr Conversion Automotive, Communications Marine Appli atiioonnss PPoowwer Conversion for Automotive, Communications and Marine Appliccaattions Choose your PowerTector Product Part Number Power Input Voltage Dimensions Weight PT10 10A continuous 9Vdc-32Vdc (Automatic Referencing) 155 x 30 x 15mm 45g PT20 20A continuous 9Vdc-32Vdc (Automatic Referencing) 155 x 30 x 15mm 45g PT40 40A continuous 9Vdc-32Vdc (Automatic Referencing) 76 x 78 x 33mm 155g PT60 60A continuous 9Vdc-32Vdc (Automatic Referencing) 76 x 78 x 33mm 155g PT100 100A continuous 9Vdc-32Vdc (Automatic Referencing) 124 x 97 x 51mm 530g PT200 200A continuous 9Vdc-32Vdc (Automatic Referencing) 124 x 97 x 51mm 530g Technical Data Input voltage range 9-32Vdc (Automatic Referencing) Output voltage Equal to input voltage when operating (maximum of 100mV drop across terminals) Transient over current rating (% of 110% for 10s continuous value) 200% for 1s 300% for <0.5ms On over current shut down there is a retry every 30s Quiescent current when shutdown Typ 2mA 13.6V, (PT40/60 Typ 4mA 13.6V) (PT100/200 Typ 6mA 13.6V) (when running) Isolation >400Vrms between input, output and case Transient voltage protection Meets ISO7637-2 International standard for 24V vehicles Electrostatic voltage protection Meets ISO10605, ISO14892, >8kV contact, 15kV discharge Operating temperature -25C to +60C to meet this specification table Storage temperature -25C to +100C Ingress protection IP65 Casework E coated aluminium, glass filled polycarbonate Connections PT10/20 Insulated 6.3mm push-on flat blade connectors PT40/60 M6 ring tongues PT100/200 M10 ring tongues and switch for additional over ride connection 6.3mm push-in flat blade connectors for earth, program, switch, override and alarm Programming lead provided Output indicator Green LED adjacent to output terminals (for programming and output indication) Mounting method PT10/20 tie wrap to wiring PT40/60/100/200 3off pozi screws Safe area protection: over current Limited by current sensing circuit Over heat Limited by temperature sensing circuit Transients Protected by filters and rugged component selection Catastrophic protection Set by external input fuse (set by application demands) and ground line fuse 1A Approvals (pending) 2004/108/EC The general EMC directive Regulation 10.04 The automotive directive 93/68/EEC The CE marking directive Markings (pending) CE and E marked Alfatronix Limited, 29 Newtown Business Park, Poole, Dorset, BH12 3LL, England Telephone: +44 (0)1202 715517. Fax: +44 (0)1202 715122 Website: www.alfatronix.com E mail: sales alfatronix.com An ISO9001:2000 Registered Company Made in the European Union by Alfatronix Ltd, Great Britain GB EU-EN-PV-0710
