IEC (529) IP67 (NEMA 1, 3, 4, 6, 12, 13) Protection DC - 3 WIRE-STANDARD Short Circuit Protection M8 Stainless Steel (SS), M12 Brass, Nickel Plated (BN), Overload Protection Cylindrical, Threaded, 10-30V DC, 250mA, Reverse Polarity Protection LED for Output Energized Wire Break Resistance Transient Voltage Protection Temperature Range: -25 to 70C (-13 to 158F) M8 Flush Mount M12 Flush Mount Sensing Distance 1.5mm (0.06 in.) 2mm (.08 in.) Cable or Connector Style Cat. No. Cable 65 Cable 65 Normally Open AIS08F1.5AP024-2M AIS08F1.5AP024-Q65 AIS12F02AP024-2M AIS12F02AP024-Q65 PNP Complementary NO/NC* AIS12F02UP024-2M AIS12F02UP024-Q65 Normally Open AIS08F1.5AN024-2M AIS08F1.5AN024-Q65 AIS12F02AN024-2M AIS12F02AN024-Q65 NPN Complementary NO/NC* AIS12F02UN024-2M AIS12F02UN024-Q65 Ripple Voltage 10% 10% Voltage Range 10-30V 10-30V No-Load Current 11 mA 15mA Max. Load Current 250 mA 250 mA Voltage Drop Across Sensor 1.3V 2.5V Max. Leakage Currrent 1 A 1A Switching Frequency 2000 Hz 1000 Hz Hysterisis 0.15mm 0.2mm Temperature Drift 3m/K 4m/K Repeatability 0.05mm 0.1mm Fixed Cable PVC 2m (6ft. 6in.). For other cable lengths and/or PUR cable, 4 please consult Altech. M8 is 4 A/F 13 A/F 17 LED LED supplied with stainless steel locknuts and M12 is supplied with brass, nickel plated locknuts. 40 48 60 80 50 65 Style Connector 4 A/F 13 4 LED A/F 17 4-pin, Micro style, 12mm (.47 in.). LED 1 1 M8 is supplied with stainless 44 44 steel locknuts and M12 is 24 24 supplied with brass, nickel plated locknuts. 3 44 3 44 72 70 ** NNoottee sshhoorrtt cciirrccuuiitt pprrootteeccttiioonn iiss ppeennddiinngg ccoonnttaacctt AAlltteecchh.. NNoottee:: SSeennssoorr ddiimmeennssiioonnss iinn mmmm.. Altech Corp. 35 Royal Road Flemington, NJ 08822-6000 Phone (908) 806-9400 Fax (908) 806-9490 8 M8x1 M8x1 M12x1 4 M12x1 M12x1 9 11 M12x1 5Metric/in. Conversion Table This table converts 1.5 mm = .06 in. 23.0 mm = .08 in. millimeters to inches 2.0 mm = .08 in. 28.0 mm = 1.10 in in reference to the 4.0 mm = .16 in 30.0 mm = 1.18 in. illustrations included 5.0 mm = .20 in. 32.0 mm = 1.26 in. on these pages. 6.0 mm = .23 in. 34.0 mm = 1.34 in. If you do not see a 8.0 mm = .31 in. 40.0 mm = 1.57 in. coverted dimension, 10.0 mm = .39 in. 50.0 mm = 1.97 in. multiply mm by 12.0 mm = .47 in. 51.0 mm = 2.01 in. 0.03937 to convert to 15.0 mm = .59 in. 60.0 mm = 2.36 in. inches. 18.0 mm = .70 in. 80.0 mm = 3.12 in. M12 Non-Flush Mount 4mm (.16 in.) Wiring Diagrams Cable 65 Note: Wire colors are applicable on cables AIS12N04AP024-2M AIS12N04AP024-Q65 purchased from Altech AIS12N04UP024-2M AIS12N04UP024-Q65 PNP NPN AIS12N04AN024-2M AIS12N04AN024-Q65 Fixed Cable Fixed Cable + + BR BR AIS12N04UN024-2M AIS12N04UN024-Q65 LOAD BK 10% BK LOAD 10-30V BL BL 15mA Normally Open Normally Open 250 mA 2.5V Cable Connector Cable Connector 1A + + BR BR LOAD BK (N.O.) BK (N.O.) 1000 Hz WH (N.C.) WH (N.C.) 0.6mm LOAD 8m/K BL BL NO / NC NO / NC 0.3mm 65 Connector 65 Connector BR + BR + 1 4 LOAD BK 1 4 BK LOAD 2 3 BL BL 2 3 Normally Open Normally Open 4 A/F 17 LED 65 Connector 65 Connector BR + BR + LOAD 4 1 1 4 BK(N.O.) LOAD 4 (N.C.) BK(N.O.) LOAD 8 WHT BL BL 40 2 3 LOAD 2 3 (N.C.) 60 WHT NO / NC NO / NC 80 4 A/F 17 LED 4 8 40 70 NNoottee:: SSeennssoorr ddiimmeennssiioonnss iinn mmmm.. Altech Corp. 35 Royal Road Flemington, NJ 08822-6000 Phone (908) 806-9400 Fax (908) 806-9490 9 M12x1 M12x1 9 11 M12x1 5
