Multi-Channel Fiber Optic Circular
Amphenol
Aerospace
(CF38999 Connector) How to Order
38999
Easy Steps to build a part number... Tri-Start Series III
III
1. 2 3 4. 5. 6.
HD
Connector Type Material Finish Shell Style Shell Size- Insert Contact Type & Key/
Arrangement Keyway Position Dualok
CF 50 9 0 17-08 P II
I
Amphenol Multi-Channel fiber optic connectors for use with multi-mode and single mode ter mini can be
SJT
ordered by coded par t number . Order ing procedure is illustrated by par t number CF-509017-08P as shown above:
Accessories
Aquacon
Herm/Seal
Step 1. Connector Type Step 6. Select a Contact Type &
Key/Keyway Position
PCB
Designates
Contact Type and Key/Keyway Position
Multi-Channel Fiber Optic Connector
CF
P designates pin contacts
HIHg
S designates socket contacts
SPeeD
For key/keyway positioning, choose the alter nate
Step 2. Select a Material
Fiber
rotation suffix letter from the char t below .
Optics
Designates
ALTERNATE POSITION SUFFIX
50 Aluminum shell Contacts
Suffix Letter
Alter nate
Connectors
60 Composite shell
Position Cables
Pins Sockets
80 Stainless steel shell
Nor mal P S
A G H
B I J
Step 3. Select a Finish
C K L
Designates
D M N
Electroless nickel plated aluminum, 48 hour salt spray
4
E R T
resistance, 200C
For more infor mation on key/keyway rotation,
5 Unplated composite
see the Ser ies III MIL-DTL-38999 Section .
6 Corrosion resistant stainless steel, 500 hour salt spray
resistance, 200C
9 Corrosion resistant olive drab cadmium plate alumin um,
500 hour salt spray resistance, 175C
TM
D Designates Dur malon (Nickel-PTFE)*
S Nickel plated stainless steel
Step 4. Select a Shell Style
Designates
0 Wall mount receptacle
1 Line receptacle
2 Box mount receptacle
Straight plug less ground strap
5
Straight plug
6
7 Jam nut receptacle
Step 5. Select a Shell Size Insert Arrangement
from proceeding pages.
Shell Size & Inser t Arrangement are on page 194 .
First number represents Shell Size, second number is the
Inser t Arrangement .
*Dur malon is a trademar k of Amphenol . For more infor mation on Dur malon see page 5 .
Contact Amphenol Aerospace for more infor mation at 800-678-0141 www .amphenol-aerospace com .
193Multi-Channel Fiber Optic Circular
Amphenol
Aerospace
Inser t Availability, (CF38999 Connector)
38999 Fiber optic ter mini can be accommodated in any size 16 or size 20 contact cavity of
MIL-DTL-38999 Ser ies III type connector inser t patter ns, as listed in the following char t .
III
For availability of fiber type, either multi-mode or single mode, see note at bottom of char t .
HD
Contact Size
Dualok
Shell Size/ Total Optic Ter mini
8
12 10 8
II
Arrangement Contacts Availability*
22D 12 (Twinax)
(Coax) (Power) (Coax)
20 16 F
I
2 2
09-94
SJT
3 3
09-98
Accessories
2 2
11-02
5 5
11-05
Aquacon
6 6
11-98
Herm/Seal
7 7
11-99
4 4
PCB 13-04
8 8
13-08
4 2** 2
13-13
HIHg
10 10
13-98
SPeeD
5 5
15-05
Fiber 15 14 1
15-15
Optics
18 18
15-18
19 19
15-19
Contacts
12 8 4
15-97
Connectors
8 8
17-08
Cables
26 26
17-26
23 21 2
17-99
11 11
19-11
28 26 2
19-28
32 32
19-32
16 16
21-16
27 19 4 4
21-29
39 37 2
21-39
21-41 41 41
23-21 21 21
23-53 53 53
23-54 53 40 9 4
23-55 55 55
25-04 56 48 8
25-11*** 11 2 9
25-20*** 30 10 13 4 3
25-24 24 12 12
25-26 25 16 5 4
25-29 29 29
25-37 37 37
25-41 41 22 3 11 2 3
25-43 43 23 20
25-46 46 40 4 2
25-61 61 61
25-90 46 40 4 2
25-F4 66 49 13 4
* Size 16 multi-mode and single mode fiber optic ter mini are readily available .
For size 20 multi-mode ter mini consult Amphenol Aerospace for availability .
** Two size 16 contacts dedicated to fiber optics .
*** For use in MIL-STD-1760 applications . See 38999 Ser ies III section in this catalog .
For RG180/U and RG195/U cables only . Contact Amphenol for other cable
applications .
F Size 8 coax and Twinax are interchangeable .
For ser vice ratings and perfor mance of electr ical contacts see 38999 Ser ies III section in this catalog .
194 Contact Amphenol Aerospace for more infor mation at 800-678-0141 www .amphenol-aerospace .com
