D-SUBMINIATURE MILITARY PRODUCTS DM SERIES Amphenols D-Subminiature connectors are part of an industrystandard for applications requiring robust and reliable connectors. These proven D-Subminiature connectors are one of the most popular Input/Output interconnects, addressing a wide variety of applications in Telecommunications, Data, Consumer, Industrial, Military, Instrumentation and Medical. Since many years Amphenol has been offering a wide range of D-Subminiature connectors to meet various design requirements including those in harsh environment. These high performance connectors are designed for severe environment applications in the field of Telecommunications - data transmission, private TARGET MARKETS automatic branch switching... Connectors for Aerospace, military (125C) class and for particularly severe applications, especially high temperature (+155C) class available. It features machined contacts and is available with solder bucket, straight spills, angled spills and wire wrap terminations. FEATURES BENEFITS Military grade machined contact connectors Suitable for high performance Aero-Mil applications Available in Straight, Angle, Wire Wrap, Solder Bucket, Support both PCB & Cable mounting requirements Crimp terminations Various PCB and Panel mounting accessory options Wide variety of choices for secure connection available Cadmium plated shells,Green insulators & colour coded Comply with MIL-C-24308 standard Crimp contacts Hoods available in plastic, metalized and metallic form Supports cable connection Prevents risks of pulling up and with locking screws accidental un-mating Amphenol Information Communications and Commercial Products www.amphenol-icc.comD-SUBMINIATURE MILITARY PRODUCTS DM SERIES DM SERIES HE 501 UL RATING PRODUCT E66906 For aerospace, military 125 class-European standard in compliance with NFC 93425/HE 501 Shell plating: Cadmium Military and Aero applications ORDERING INFORMATION D B M L 25 P 5 00 M Series: Plating D*M Standard = Gold/Nickel 00 Shell Size (Blank for solder bucket termination) E Number of Please consult us Others Contacts A 09 B Termination 15 C Solder buckets Blank 25 D Straight solder spills 3 37 Angled solder spills 5 Characterisation of 50 Military series Wire wrap (3 levels) 4 Options 1 Version Options 2 Angled Spills Other Terminations Standard mounting hole ( = 3.10) Blank Blank Plastic bracket Not applicable Threaded insert M3 L Contacts C Without brackets Not applicable Float mounting F Pin P M Metal brackets Not applicable Socket S Disclaimer www.amphenol-icc.com Please note that the above information is subject to change without notice.
