L17D440SP Amphenol

RR-HR D-Sub connectors - Stamped and Formed Contacts REAR RELEASE CRIMP CONNECTORS Designed for high volume Specifications production, Amphenol s rear Connectors according to MIL C24308 release crimp connector and contacts provide significant cost Materials and Platings saving. Shells Tinned steel with or without dimples on plug connector - EMI / RFI shell configuration. Insulator Black glass-filled thermoplastic, UL 94V-0 - Removable, reusable contacts. Boardlock Brass, 3m up to 5m (118 up to 197 ) - Automatic and manual tooling tinned over nickel 2m up to 3m available. (78 up to 118 ) Screwlock Brass, 6m up to 10m (236 up to 394 ) tinned over nickel 2m up to 3m (78 up to 118 ) Contacts Under plating Crimp side 0.2m (8 ) gold 2m (78 ) nickel gold flash or tin 0.5m (20 ) gold 2m (78 ) nickel gold flash or tin Simplify Simplify 0.76m (30 ) gold 2m (78 ) nickel gold flash or tin your cable your cable Electrical Data assemblies assemblies Current rating 5A Voltage rating 500V AC/rms 50Hz Withstanding voltage RR: 1000V AC/rms 50Hz for 1 minute HR: 1000V AC/rms 60Hz for 1 minute Insulation resistance RR: 5000M HR: 1000M Commercial Contact resistance 10m max Industrial Wire size 20-28 AWG max insulation 1.27mm (.05 ) Telecom Any industry standard I / O connections Climatic Data Operating temperature -55C to +125C Mechanical Data Mating and unmating force Unit: kg ( lb) No. of Cts Mate (max) Unmate (min) RR HR RR HR RR HR 9 (size E) 15 (size E) 3.05 (6.74) 3.81 (8.42) 0.36 (0.79) 0.52 (1.14) 15 (size A) 26 (size A) 5.09 (11.24) 5.95 (13.16) 0.46 (1.01) 1.05 (2.32) 25 (size B) 44 (size B) 8.44 (18.66) 9.26 (20.46) 0.81 (1.8) 1.37 (3.02) 37 (size C) 62 (size C) 12.51 (27.65) 13.48 (29.78) 1.1 (2.47) 1.76 (3.88) 50 (size D) 78 (size D) 14.65 (32.38) 15.82 (34.96) 1.6 (3.56) 2.02 (4.46) CHARACTERISTICS APPLICATIONS DESCRIPTION RR-HR / E11Standard density RR A0.38 (.015) B0.13 (.005) C0.13 (.005) D0.13 (.005) E0.05 (.002) POSITION 1 10 3.05 (.120) X PLUG SOCKET 10.72 (.422) numbered cavities F0.13 (.005) DIMENSIONS mm (inch) Nb OF CONTACTS A B C D E F X 9 30.84 (1.21) 24.99 (.98) 16.92 (.67) 16.24 (.64) 11.09 (.44) 19.28 (.76) 2.74 15 39.24 (1.54) 33.32 (1.31) 24.7 (.972) 24.56 (.97) 19.39 (.76) 27.51 (1.08) 2.74 25 53.04 (2.09) 47.04 (1.85) 38.96 (1.53) 38.38 (1.51) 33.24 (1.31) 41.30 (1.63) 2.77 37 69.32 (2.73) 63.50 (2.50) 55.42 (2.18) 54.76 (2.16) 49.86 (1.96) 57.71 (2.27) 2.77 50 67 (2.64) 61.11 (2.41) 52.86 (2.08) 52.34 (2.06) 44.32 (1.75) 55.3 (2.18) 2.77 A0.38 (.015) B0.13 (.005) C0.13 (.005) D0.13 (.005) E0.13 (.005) POSITION 1 10 3.05 (.120) X PLUG SOCKET 2 13.56 (.534) numbered cavities F0.38 (.015) OVERALL DIMENSIONS 5.9 (.232) 5.9 (.232) 11 (.433) 11 (.433) 11.20.13 (.441.005) 8.380.13 (.33.005) 2.84 2.84 (.112) 2.84 (.112) 11.2 (.441) 6.1 (.240) 11.2 (.441) 6.1 (.240) 10.9 (.429) 10.9 (.429) 7.90.13 (.311.005) 5.8 (.228) 5.8 (.228) 12.550.38 (.494.015) 10.90.13 (.429.005) 15.370.38 (.605 .015)
