1399G20-BK Anderson Power Products

POWERPOLE PP75 Powerpole Connectors PP75 - Up to 120 Amps PP75 series Powerpole housings can be used for wire-to-wire, wire-to-board, and wire-to-busbar applications. Wire sizes from 16 to 6 AWG (1.3 to 13.3 mm) offer power capabilities up to 120 amps per pole. Locking housings offer the capability to secure Powerpole housings to each other and to mounting pads. Housings made from chemical resistant (CR) resin withstand industrial solvents beer than stt tandard housings. Large Wire Range Accommodates up to 6 (10 mm) Wire Reducing bushings allow as small as 16 AWG (1.5 mm) PP75 with Mounting Wings wire to be used Wire, PCB, and Busbar Contacts Allows one connection system to meet multiple needs Mini-Powerclaw PCB Contacts Minimize PCB Footprint Removes the PP75 housing from the board side PP75 ORDERING INFORMATION PP75 Standard Housings The second smallest Powerpole housing can be used with wire contacts up to 6 AWG (10 mm) as well as PCB and busbar contacts. 15.9 0.62 47.9 Description Part Numbers 1.88 Minimum Quantity 1,000 100 15.9 17.0 Red 5916G7-BK 5916G7 0.62 0.67 Green 5916G6-BK 5916G6 81.3 Black 5916G4-BK 5916G4 3.20 White 5916G5-BK 5916G5 Front View Mated Length Blue 5916-BK 5916 Yellow 5916G15-BK 5916G15 Orange 5916G14-BK 5916G14 Gray 5916G16-BK 5916G16 PP75 Chemical Resistant (CR) Housings V0 = Standard Material ID Has the same form and dimensions of the standard Located Here P = Chemical Resistant PP75 housing in a chemical resistant PBT / PC blend housing. Suitable for use to -40C. Description Part Numbers Minimum Quantity 1,000 Red P5916G7-BK Black P5916G4-BK White P5916G5-BK Blue P5916-BK PP75 Locking Dovetail Housings Offers dovetails for stacking housings that have a locking feature to prevent housings separating. Can mate to standard and chemical resistant housings, but cannot be stacked with them. Description Part Numbers 47.9 Minimum Quantity 1,000 100 1.88 Red 75LOKRED-BK 75LOKRED Green 75LOKGRN-BK 75LOKGRN Black 75LOKBLK-BK 75LOKBLK White 75LOKWHT-BK 75LOKWHT Blue 75LOKBLU-BK 75LOKBLU Gray 75LOKGRA-BK 75LOKGRA - 41 - All Data Subject To Change Without Notice www.andersonpower.comPP75 Premate Ground Housings Offers a first-mate, last-break connection when stacked together with PP75 Mated Length housings. Stacks together with PP75 standard and chemical resistant housings. Housings are mechanically keyed to prevent cross mating with power positions. Description Part Numbers Minimum Quantity 1,000 100 83.1 3.20 Green 5927G6-BK 5927G6 PP75 Silver Plated Wire Contacts Silver plated contacts offer the best electrical performance and durability up to 10,000 mating cycles. See reducing bushings in accessory section for smaller wires. Dimensions Mating Loose Piece - A - AWG mm Force Part Numbers inches mm Minimum Quantity 1,000 100 6 13.3 Low 1307-BK 1307 0.22 5.59 11.1 30.0 6 13.3 High 5900-BK 5900 0.22 5.59 0.44 1.18 8 8.4 High 5952-BK 5952 0.19 4.83 A 12 to 10 3.3 to 5.3 Low 5953-BK 5953 0.14 3.56 7.2 12 to 10 3.3 to 5.3 High 5915-BK 5915 0.14 3.56 7.1 0.28 0.28 PP75 Premate Ground Wire Contacts Silver plated contacts for use with the PP75 Premate Ground Housing. Rated to 10,000 mating cycles. Dimensions 32.0 Loose Piece - A - 1.26 Type AWG mm Part Numbers inches mm Minimum Quantity 1,000 100 11.9 Individual 6 13.3 1875G1-BK 1875G1 0.22 5.59 0.47 Individual 8 8.4 1875G2-BK 1875G2 0.19 4.83 Individual 12 to 10 3.3 to 5.3 1875G3-BK 1875G3 0.14 3.56 7.2 7.1 0.28 0.28 PP75 Silver Plated Busbar Contacts Provide a quick disconnect input or output busbar connection. Busbar contacts are for mating with wire contacts only. Part number 75BBS includes lock nuts. Locknuts must be ordered separately for B01915P1. Mating See Busbar contact drawing on 17.1 Type Thread Force Part Numbers 0.68 website for further detail. Minimum Quantity 1,000 20 10 Busbar 10-24 High B01915P1 - 75BBS Lock Nut 10-24 - H1216P8 110G54 - 2.0 0.08 69.1 2.72 55A Right Angle Standard Powerclaw PCB Contacts Standard Powerclaw contacts are for use inside a PP75 housing and provide a color-coded right angle connection to the PCB. Description Loose Piece Part Numbers Minimum Quantity 500 100 Tin Plated PC5930T-BK PC5930T 5.2 PP75 Housing 17.0 0.20 Silver Plated PC5930S-BK PC5930S 0.67 22.2 0.87 48.0 Standard 1.89 See PCB contact 66.0 Powerclaw 2.60 drawing on website Contact 32.8 for further detail. 1.29 Second housing and contact in two pole version only. - 42 - All Data Subject To Change Without Notice www.andersonpower.com POWERPOLE PP75
