Part Number PPC405EP
Revision 1.08 March 24, 2008
Data Sheet
PPC405EP
PowerPC 405EP Embedded Processor
Features
- Asynchronous PCI Bus interface
AMCC PowerPC 405 32-bit RISC processor
- Internal or external PCI Bus Arbiter
core operating up to 333MHz with 16KB D-
and I-caches
Two Ethernet 10/100Mbps (full-duplex) ports
with media independent interface (MII)
PC-133 synchronous DRAM (SDRAM) inter-
face
Programmable interrupt controller supports
seven external and 19 internal edge-triggered
- 32-bit interface for non-ECC applications
or level-sensitive interrupts
4KB on-chip memory (OCM)
Programmable timers
External peripheral bus
Software accessible event counters
- Flash ROM/Boot ROM interface
Two serial ports (16750 compatible UART)
- Direct support for 8- or 16-bit SRAM and
One IIC interface
external peripherals
General purpose I/O (GPIO) available
- Up to five devices
Supports JTAG for board level testing
DMA support for memory and UARTs.
Internal processor local bus (PLB) runs at
- Scatter-gather chaining supported
SDRAM interface frequency
- Four channels
Supports PowerPC processor boot from PCI
PCI Revision 2.2 compliant interface (32-bit, up
memory
to 66MHz)
Description
Designed specifically to address embedded Ethernet interface, control for external ROM and
applications, the PowerPC 405EP (PPC405EP) peripherals, DMA with scatter-gather support, serial
provides a high-performance, low-power solution that ports, IIC interface, and general purpose I/O.
interfaces to a wide range of peripherals by
Technology: CMOS SA-27E, 0.18 m (0.11 m L )
eff
incorporating on-chip power management features
Package: 31mm, 385-ball, enhanced plastic ball grid
and lower power dissipation requirements.
array (E-PBGA)
This chip contains a high-performance RISC
Power (typical): 0.72W at 266MHz
processor core, SDRAM controller, PCI bus interface,
AMCC 1Revision 1.08 March 24, 2008
PPC405EP PowerPC 405EP Embedded Processor
Data Sheet
Table of Contents
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Ordering, PVR, and JTAG Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Address Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
PLB to PCI Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
SDRAM Memory Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
External Peripheral Bus Controller (EBC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
DMA Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Serial Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
IIC Bus Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
General Purpose IO (GPIO) Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Universal Interrupt Controller (UIC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10/100 Mbps Ethernet MAC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
JTAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Pin Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Signal List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Document Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
2 AMCC
