8719NH.00305 Belden

TECHNICAL DATA SHEET code 8719NH version 4 date 2007-02-14 page 8719NH 1/2 APPLICATION Instrumentation and computer cable for data transmission applications. CONSTRUCTION 1. Conductor 2. Insulation 3. Foil 4. Drainwire 5. Sheath 1. Conductor AWG16 (19xAWG29) tinned Cu 2. Insulation Material Polyethylene Diameter over insulation 3.10 0.07 mm Colour of insulation Black and Transparent 3. Foil Material Aluminium / Polyester Thickness 9 / 23 m 4. Drainwire AWG18 (16xAWG30) tinned Cu 5. Sheath Material FRNC Colour Chrome (like RAL 7037) Nominal diameter 8.10 mm REQUIREMENTS AND TEST METHODS Electrical: Max. continuous current per conductor 25 C 7 A Nominal capacitance conductors of pair 1 kHz 75.4 pF/m Nominal capacitance conductor to shield 1 kHz * 144.4 pF/m Nominal inductance of pairs 0.66 H/m Nominal resistance conductor 14.76 /km Nominal resistance shield 20.00 /km Nominal impedance 65 Ohm *One conductor to other conductor and shield. Nominal Values are for information only. Belden Wire & Cable B.V. All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner TECHNICAL DATA SHEET code 8719NH version 4 date 2007-02-14 page 8719NH 2/2 Mechanical and physical: Flame resistance IEC 60332-3C Oil resistance ASTMD741 Radiation resistance IEC544 (CERN) Application specification BS 7655 section 6.1 table 1, LTS 3 Halogen content according to IEC754-1 zero Corrosivity of fire gasses according to IEC754-2 Conductivity 100 S/cm pH value 3.5 Temperature range installing -15 to +80 C Temperature range operating (moving installation) -15 to +80 C Temperature range operating (fixed installation) -45 to +80 C Temperature range storage -45 to +80 C Nominal weight approx. 9.5 kg/100m PACKAGING On non-returnable reels with a nominal length of 1000m (-0, 0%). Each reel is labelled with the following data: Belden Logo. Belden code number. Item description. Length on the reel. Date of manufacture. CE-marking. Belden declares this product to be in compliance with the environmental regulations EU RoHS (Directive 2002/95/EC, 27 January 2003) this is valid for all material produced after the RoHS compliant date for this product. Belden Wire & Cable B.V. All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner
