8723.0030 Belden

Name: 8723.0030
Brand: Belden
SKU: 87230030_Belden
Availability: InStock
Rating: 5 (11 reviews)

8723.0030 electronic component of Belden

Images are for reference only
See Product Specifications

Part No.	8723.0030
Manufacturer:	Belden
Category:	Multi-Conductor Cables
Description:	SHIELDED CABLE, 2PAIR, 22AWG, 30.5M
Datasheet:	8723.0030 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 239.17 ea
Line Total: USD 239.17

Availability - 76
Ship by Mon. 25 Nov to Fri. 29 Nov

MOQ: 1 Multiples: 1
Pack Size: 1

8723.0030 More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

76

Ship by Mon. 25 Nov to Fri. 29 Nov

MOQ : 1
Multiples : 1

1 : USD 239.17

Specifications

Manufacturer
Belden Belden

Product Category
Multi-Conductor Cables Multi-Conductor Cables

Jacket Colour
Chrome Chrome

Jacket Material
PVC PVC

Conductor Material
Tinned Copper Tinned Copper

Voltage Rating
300 V 300 V

Brand
Belden Belden

Cable Shielding
Screened Screened

No. Of Pairs
2 Pair 2 Pair

Wire Gauge
22AWG 22AWG

Conductor Area Csa
0.325mm² 0.325mm²

Reel Length Imperial
100 ft 100 ft

Reel Length Metric
30.5 m 30.5 m

No. Of Max Strands X Strand Size
7 x 30 AWG 7 x 30 AWG

External Diameter
4.064 mm 4.064 mm

Svhc
No SVHC (15 - Jan - 2018) No SVHC (15 - Jan - 2018)

Alpha Type Number
2466C EQUIVALENT 2466C EQUIVALENT

Belden Type Number
8723 8723

Cable Type
Shielded Shielded

Complex Cable Make-Up
4 x 7/30 4 x 7/30

Conductor Make-Up
7 / 30AWG 7 / 30AWG

Core - Core Capacitance
115 pF /m 115 pF /m

Core-Screen Capacitance
203 pF /m 203 pF /m

Current Rating
2.3 A 2.3 A

Drain Wire Type
Integral Integral

Impedance
52 Ohms 52 Ohms

No. Of Cores
4Core 4Core

Screen Type Primary
Aluminium Polyester Aluminium Polyester

Secondary Insulation Colour
Grey Grey

Secondary Insulation Material
PVC PVC

Velocity Of Propagation
66 % 66 %

Wire Size
22 AWG 22 AWG

Notes:- Show Stocked Products With Similar Attributes.
