Product: 9180 Audio Cable, 26-1pr, TC, O/A Foil, CM Product Description 110 Ohm, 26 AWG stranded (7x34) .018 TC conductors, Datalene insulation, twisted pair, Beldfoil shield (100% coverage), 26 AWG stranded TC drain wire, PVC jacket. Technical Specifications Physical Characteristics (Overall) Conductor AWG Stranding Material Nominal Diameter No. of Pairs 26 7x34 TC - Tinned Copper 0.019 in 1 Conductor Count: 2 Total Number of Pairs: 1 Insulation Material Material Trade Name Nominal Diameter Nominal Wall Thickness PE - Polyethylene (Foam) Datalene 0.049 in 0.015 in Color Chart Number Color 1 Black & White Outer Shield Type Material Material Trade Name Coverage % Drainwire Material Drainwire Diameter Drainwire AWG Drainwire Construction n x D Bi-Laminate Tape Beldfoil 100% TC - Tinned Copper 0.019 in 26 7x34 (Alum+Poly) Outer Jacket Material Nominal Diameter Nominal Wall Thickness PVC - Polyvinyl Chloride 0.144 in 0.022 in Electrical Characteristics Conductor DCR Nominal Conductor DCR Nominal Conductor DCR Conductor Resistance Nominal Outer Shield DCR 37.3 Ohm/1000ft 37.3 Ohm/1000ft 23.1 Ohm/1000ft Capacitance Nom. Capacitance Conductor to Conductor Nom. Capacitance Conductor to Other Conductor to Shield 13 pF/ft 26 pF/ft Inductance Nominal Inductance 0.23 H/ft Impedance Nominal Characteristic Impedance 110 OhmHigh Frequency (Nominal/Typical) Frequency MHz Nom. Insertion Loss 0.38 MHz 0.84 dB/100ft 0.77 MHz 1.18 dB/100ft 1 MHz 1.34 dB/100ft 1.5 MHz 1.54 dB/100ft 2 MHz 1.69 dB/100ft 3.1 MHz 1.92 dB/100ft 4.1 MHz 2.14 dB/100ft 5.6 MHz 2.4 dB/100ft 8.2 MHz 2.75 dB/100ft 11.3 MHz 3.09 dB/100ft 12.3 MHz 3.18 dB/100ft 24.6 MHz 4.2 dB/100ft Delay Nominal Delay Nominal Velocity of Propagation (VP) % 1.34 ns/ft 76% High Frequency Frequency MHz 0.38 MHz 0.77 MHz 1 MHz 1.5 MHz 2 MHz 3.1 MHz 4.1 MHz 5.6 MHz 8.2 MHz 11.3 MHz 12.3 MHz 24.6 MHz Current Max. Recommended Current A 1.9 Amps per Conductor at 25C Voltage UL Voltage Rating 300 V RMS Temperature Range Non-UL Temp Rating: 75C Operating Temp Range: -40C To +75C Mechanical Characteristics Bulk Cable Weight: 10 lbs/1000ft Max. Pull Tension: 10.5 lbs Min. Bend Radius/Minor Axis: 1.5 in Standards NEC/(UL) Compliance: CMR CEC/C(UL) Compliance: CMG CPR Euroclass: Eca Other Specification: AES/EBU Applicable Environmental and Other Programs Environmental Space: Indoor - Riser EU Directive 2000/53/EC (ELV): Yes
