Detailed Specifications & Technical Data ENGLISH MEASUREMENT VERSION 9222 Coax - 50 Ohm Triax For more Information please call 1-800-Belden1 General Description: RG-58A/U type, 20 AWG stranded (7x28) .037 tinned copper conductor, polyethylene insulation, double tinned copper braid shields (95% coverage), PVC jacket. Physical Characteristics (Overall) Conductor AWG: Coax AWG Stranding Conductor Material Dia. (in.) 1 20 7x28 TC - Tinned Copper 0.038 Total Number of Conductors: 1 Insulation Insulation Material: Insulation Material Dia. (in.) PE - Polyethylene 0.120 Inner Shield Inner Shield Material: Type Inner Shield Material Coverage (%) Braid TC - Tinned Copper 95.000 Inner Jacket Inner Jacket Material: Inner Jacket Material Nom. Dia. (in.) PE - Polyethylene 0.177 Outer Shield Outer Shield Material: Type Outer Shield Material Coverage (%) Braid TC - Tinned Copper 95.000 Outer Jacket Outer Jacket Material: Outer Jacket Material Nom. Wall Thickness (in.) PVC - Polyvinyl Chloride 0.021 Overall Cable Overall Nominal Diameter: 0.241 in. Mechanical Characteristics (Overall) Operating Temperature Range: -40C To +75C Non-UL Temperature Rating: 75C Bulk Cable Weight: 39 lbs/1000 ft. Max. Recommended Pulling Tension: 83 lbs. Min. Bend Radius/Minor Axis: 2.500 in. Applicable Specifications and Agency Compliance (Overall) Applicable Standards & Environmental Programs EU Directive 2011/65/EU (ROHS II): Yes EU CE Mark: Yes EU Directive 2000/53/EC (ELV): Yes EU Directive 2002/95/EC (RoHS): Yes EU RoHS Compliance Date (mm/dd/yyyy): 01/01/2004 EU Directive 2002/96/EC (WEEE): Yes EU Directive 2003/11/EC (BFR): Yes Page 1 of 3 01-05-2017Detailed Specifications & Technical Data ENGLISH MEASUREMENT VERSION 9222 Coax - 50 Ohm Triax CA Prop 65 (CJ for Wire & Cable): Yes MII Order 39 (China RoHS): Yes RG Type: 58A/U Plenum/Non-Plenum Plenum (Y/N): No Electrical Characteristics (Overall) Nom. Characteristic Impedance: Impedance (Ohm) 50 Nom. Inductance: Inductance (H/ft) .077 Nom. Capacitance Conductor to Shield: Capacitance (pF/ft) 30.8 Nominal Velocity of Propagation: VP (%) 66 Nom. Conductor DC Resistance: DCR 20C (Ohm/1000 ft) 9.5 Nom. Inner Shield DC Resistance: DCR 20C (Ohm/1000 ft) 4.7 Nominal Outer Shield DC Resistance: DCR 20C (Ohm/1000 ft) 4.3 Nom. Attenuation: Freq. (MHz) Attenuation (dB/100 ft.) 1 .5 10 1.5 50 3.3 100 4.9 200 7.2 400 12.0 500 14.0 700 18.0 900 22.0 1000 24.0 Max. Operating Voltage - Non-UL: Voltage 1400 V RMS Put Ups and Colors: Item Putup Ship Weight Color Notes Item Desc 9222 004U500 500 FT 20.500 LB YELLOW 50 OHM TRIAX 9222 004100 100 FT 4.600 LB YELLOW 50 OHM TRIAX 9222 004500 500 FT 21.000 LB YELLOW C 50 OHM TRIAX Notes: C = CRATE REEL PUT-UP. Revision Number: 3 Revision Date: 09-28-2012 2017 Belden, Inc All Rights Reserved. Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described herein are subject to error or omission and to change without notice, and the listing of such information and specifications does not ensure product availability. Belden provides the information and specifications herein on anAS I basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein. All sales of Belden products are subject to Belden s standard terms and conditions of sale. Belden believes this product to be in compliance with EU RoHS (Directive 2002/95/EC, 27-Jan-2003). Material manufactured prior to the compliance date may be in stock at Belden facilities and in our Distributors inventory. The information provided in this Product Disclosure, and the identification of materials listed as reportable or restricted within the Product Disclosure, is correct to the best of Beldens knowledge, information, and belief at the date of its publication. The information provided in this Product Disclosure is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual usage of the product. Page 2 of 3 01-05-2017
