9272 Belden

Name: 9272
Brand: Belden
SKU: 9272_Belden
Availability: OutOfStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	9272
Manufacturer:	Belden
Category:	Unclassified
Description:	CABLE, 9272, TWINAX, PER M
Datasheet:	9272 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 22.3435 ea
Line Total: USD 22.34

Availability - 0

MOQ: 1 Multiples: 1
Pack Size: 1

9272 More Buying Options & Price Grid(s)

Availability	Price	Buy Price	Quantity
0 Ship by Fri. 22 Nov to Thu. 28 Nov MOQ : 1 Multiples : 1	1 : USD 22.3435

Specifications

Manufacturer Belden Belden
Product Category Unclassified Unclassified
Wire Gauge 20Awg 20Awg
Conductor Area Csa 0.51Mm² 0.51Mm²
Impedance 78Ohm 78Ohm
No Of Max Strands X Strand Size 7 X 0.32Mm 7 X 0.32Mm
Reel Length Imperial - -
Reel Length Metric - -
Conductor Material Tinned Copper Tinned Copper
Jacket Material Pvc Pvc
Jacket Colour Blue Blue
External Diameter 6.2Mm 6.2Mm
Svhc No Svhc (15-Jun-2015) No Svhc (15-Jun-2015)
Alpha Type Number 9815C Equivalent 9815C Equivalent
Approval Bodies Ul Ul
Belden Type Number 9272 9272
Cable Type Braided Shield Braided Shield
Cable Ul Style Number Ul2092 Ul2092
Capacitance 64.6 pF /m 64.6 pF /m
Complex Cable Make-Up 2 X 7/28 2 X 7/28
Conductor Make-Up 7 / 28Awg 7 / 28Awg
No Of Conductors 2 2
No Of Cores 2 2
No Of Pairs 1 1
Operating Temperature Max 60 C 60 C
Operating Temperature Min - 20 C - 20 C
Outer Diameter 6.2Mm 6.2Mm
Screen Type Primary Tinned Copper Braid Tinned Copper Braid
Secondary Insulation Colour Blue Blue
Secondary Insulation Material Pvc Pvc
Velocity Of Propagation 66% 66%
Voltage Rating 300 V 300 V
Voltage Rating V Ac 300 V 300 V
Wire Size 20Awg 20Awg
