Detailed Specifications & Technical Data ENGLISH MEASUREMENT VERSION AX102006 Faceplates and Panels - KeyConnect Stainless Steel Faceplates 1-Port, Single-Gang For more Information please call 1-800-Belden1 General Description: KeyConnect Stainless Steel Faceplates 1-Port, Single Gang, Flush Usage (Overall) Suitable Applications: - Compatible with a variety of modules that are suitable for use with Belden IBDN Systems 10GX, 4800, 3600, 2400, 1200, fiber and coax. Related Parts: - Compatible with KeyConnect-style Modular Jacks 10GX, CAT6+, CAT5E and KeyConnect-style Fiber and Coax Connectors Physical Characteristics (Connectivity) Capacity Max. Capacity: 1-port Access Front Connection: Flush Dimensions Dimensions: Height (in.) Width (in.) Depth (in.) 4.500 2.750 0.260 Materials Materials: Description Material Plate Stainless Steel Weight Weight: 0.060 lbs. Included Parts Included Parts: 6-32 screw Packaging Packaging: Individually packaged in a plastic bag. Mechanical Characteristics (Connectivity) Connector/Hardware Retention: 20 lbs. Storage Temperature Range: -40C To +70C Installation Temperature Range: -10C To +60C Operating Temperature Range: -10C To +60C Applicable Specifications and Agency Compliance (Overall) Applicable Standards & Environmental Programs EU Directive 2002/95/EC (RoHS): Yes EU RoHS Compliance Date (mm/dd/yyyy): 07/01/2006 MII Order 39 (China RoHS): Yes Safety Listing: Bi-national Standard Listed Suitability Suitability - Indoor: Yes Transmission Characteristics (Connectivity) Notes (Overall) Notes: For proper installation refer to Installation Guide PX103826. Visit our web site at Detailed Specifications & Technical Data ENGLISH MEASUREMENT VERSION AX102006 Faceplates and Panels - KeyConnect Stainless Steel Faceplates 1-Port, Single-Gang 1-Port w/ ID Windows Single-gang AX104230 - AX103922 AX104160 AX104565 AX102660 AX107021 2-Port w/ ID Windows Single-gang AX104231 AX104455 AX103923 AX104161 AX104197 AX102655 AX107022 3-Port w/ ID Windows Single-gang - - AX103924 AX104162 - AX102661 - 4-Port w/ ID Windows Single-gang AX104232 AX104464 AX102248 AX104163 AX104198 AX102249 AX107023 6-Port w/ ID Windows Single-gang AX104233 - AX102250 AX104164 AX104199 AX102251 AX107024 4-Port w/ ID Windows Double-gang AX104479 - - - - - - 6-Port w/ ID Windows Double-gang AX104480 AX106594 AX102670 AX104165 AX104566 AX102671 AX107025 12-Port w/ ID Windows Double-gang AX104234 - AX102256 AX104166 AX104200 AX102257 - 1-Port Single-gang AX102006 - - - - - - 2-Port Single-gang AX102007 - - - - - - 4-Port Single-gang AX102009 - - - - - - 6-Port Single-gang AX102010 - - - - - - 6-Port Double-gang AX102012 - - - - - - 12-Port Double-gang AX102013 - - - - - - Wall Mount Phone Plate AX104126 - - - - AX102902 - Single-gang Back Box 1.89 in. - - AX104127 - - AX102657 - Double-gang Back Box 1.89 in. - - AX104130 AX106684 - AX104131 AX106685 Put Ups and Colors: Item Putup Ship Weight Color Notes Item Desc AX102006 1 EA 0.152 LB 1-PORT S/S SG FACEPLATE Revision Number: 1 Revision Date: 02-22-2010 2017 Belden, Inc All Rights Reserved. Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described herein are subject to error or omission and to change without notice, and the listing of such information and specifications does not ensure product availability. Belden provides the information and specifications herein on anAS I basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein. All sales of Belden products are subject to Belden s standard terms and conditions of sale. Belden believes this product to be in compliance with EU RoHS (Directive 2002/95/EC, 27-Jan-2003). Material manufactured prior to the compliance date may be in stock at Belden facilities and in our Distributors inventory. The information provided in this Product Disclosure, and the identification of materials listed as reportable or restricted within the Product Disclosure, is correct to the best of Beldens knowledge, information, and belief at the date of its publication. The information provided in this Product Disclosure is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual usage of the product. Page 2 of 2 08-16-2017
