MOV-07D201KTR Bourns

07D201K 5 Features Additional Information High voltagerating Click these links for more information: High current rating Bidirectional Surge protection PRODUCT TECHNICAL INVENTORY SAMPLES CONTACT Fast responsetime SELECTOR LIBRARY RoHS compliant* Agency listing: MOV-07DxxxK Series - Metal Oxide Varistor General Information Industry Standard Compliance The MOV-07DxxxK Series of 7 mm radial leaded varistor devices protects Standard UL 1449 against overvoltage transients such as lightning, power contact and power File Number E313168 induction. The metal oxide varistors offer a choice of varistor voltages from 18 V to 820 V and V voltages from 11 V to 510 V. rms The devices have a high current handling, high energy absorption capability and fast response times to protect against transient faults up to rated limits. Absolute Maximum Ratings ( T = 25 C Unless Otherwise Noted) A Parameter Symbol Min. Typ. Max. Unit Operating Temperature T -40 25 +105 C OPR Storage Temperature T -40 25 +125 C STG Rated Wattage P 0.25 Watt w Varistor Voltage Temperature Coefficient V 0 0.1 0.05 % / C TC Response Time T 10 25 ns r Varistor Voltage Tolerance V -10 0 10 % tol Electrical Characteristics ( T = 25 C Unless Otherwise Noted) A Max. Peak Max. Typ. Max. Continuous Voltage Class Current Voltage 1 mA DC (V) Current Energy Cap. Voltage (V) (8/20 s) (8/20 s) (J) (pF) Bourns Part No. Class Max. One r.m.s. d.c. Min. Nom. Max. Current Clamping 8/20 s 1 kHz Time (A) Voltage (V) MOV-07D180K 11 14 16 18 20 2.5 36 250 0.9 3840 MOV-07D220K 14 18 20 22 24 2.5 43 250 1.1 3360 MOV-07D270K 17 22 24 27 30 2.5 53 250 1.4 3120 MOV-07D330K 20 26 30 33 36 2.5 65 250 1.7 2640 MOV-07D390K 25 31 35 39 43 2.5 77 250 2.1 2400 MOV-07D470K 30 38 42 47 52 2.5 93 250 2.5 1680 MOV-07D560K 35 45 50 56 62 2.5 110 250 3.1 1440 MOV-07D680K 40 56 61 68 75 2.5 135 250 3.6 1200 MOV-07D820K 50 65 74 82 90 10 135 1200 5.5 720 MOV-07D101K 60 85 90 100 110 10 165 1200 6.5 600 MOV-07D121K 75 100 108 120 132 10 200 1200 7.8 504 MOV-07D151K 95 125 135 150 165 10 250 1200 9.7 396 MOV-07D181K 115 150 162 180 198 10 300 1200 11.7 336 MOV-07D201K 130 170 185 200 225 10 340 1200 13 300 MOV-07D221K 140 180 198 220 242 10 360 1200 14 276 MOV-07D241K 150 200 216 240 264 10 395 1200 15 252 MOV-07D271K 175 225 243 270 297 10 455 1200 18 222 MOV-07D301K 190 250 270 300 330 10 500 1200 20 198 MOV-07D331K 210 275 297 330 363 10 550 1200 23 180 MOV-07D361K 230 300 324 360 396 10 595 1200 25 168 MOV-07D391K 250 320 351 390 429 10 650 1200 25 156 MOV-07D431K 275 350 387 430 473 10 710 1200 28 138 MOV-07D471K 300 385 423 470 517 10 775 1200 30 126 MOV-07D511K 320 415 459 510 561 10 845 1200 30 120 MOV-07D561K 350 460 504 560 616 10 925 1200 30 108 MOV-07D621K 385 505 558 620 682 10 1025 1200 33 96 MOV-07D681K 420 560 612 680 748 10 1120 1200 33 90 MOV-07D751K 460 620 675 750 825 10 1240 1200 38 84 MOV-07D781K 480 640 702 780 858 10 1290 1200 38 84 MOV-07D821K 510 675 738 820 902 10 1355 1200 40 72 *RoHS Directive 2015/863, Mar 31, 2015 and Annex. Specications are subject to change without notice. WARNING Cancer and Users should verify actual device performance in their specic applications. Reproductive Harm The products described herein and this document are subject to specic legal disclaimers as set forth on the last page of this document, and at www.P65Warnings.ca.gov www.bourns.com/docs/legal/disclaimer.pdf.Applications Power supplies Power systems Line voltage Telecom systems White goods / appliances MOV-07DxxxK Series - Metal Oxide Varistor Product Dimensions Typical Part Marking This is an RoHS compliant molded radial package with 100 % Sn plating Bourns Part Number Bourns Part Marking on the terminations. MOV-07D180K 07D180K MOV-07D220K 07D220K 9.0 MAX. T (.354) MOV-07D270K 07D270K MOV-07D330K 07D330K MOV-07D390K 07D390K MOV-07D470K 07D470K 07D201K 11.0 MOV-07D560K 07D560K (.433) MAX. MOV-07D680K 07D680K MOV-07D820K 07D820K 5 MOV-07D101K 07D101K MOV-07D121K 07D121K MOV-07D151K 07D151K MOV-07D181K 07D181K 20.0 MOV-07D201K 07D201K (.787) MOV-07D221K 07D221K MIN. MOV-07D241K 07D241K MOV-07D271K 07D271K MOV-07D301K 07D301K MOV-07D331K 07D331K MOV-07D361K 07D361K MOV-07D391K 07D391K 0.6 0.1 MOV-07D431K 07D431K MM (.024 .004) DIMENSIONS: MOV-07D471K 07D471K 5.0 0.8 (INCHES) MOV-07D511K 07D511K (.197 .031) MOV-07D561K 07D561K Bourns Part Dim. T Bourns Part Dim. T MOV-07D621K 07D621K Number (Max.) Number (Max.) MOV-07D681K 07D681K 3.4 3.6 MOV-07D751K 07D751K MOV-07D180K MOV-07D241K (.134) (.142) MOV-07D781K 07D781K 3.5 3.8 MOV-07D220K MOV-07D271K MOV-07D821K 07D821K (.138) (.150) NOTE: The 5 marking on MOV products is for traceability of production 3.8 4.0 MOV-07D270K MOV-07D301K assembly for quality assurance compliance. (.150) (.157) 3.4 4.2 MOV-07D330K MOV-07D331K How to Order (.134) (.165) 3.6 4.4 MOV - 07D nn (n) K (TR) MOV-07D390K MOV-07D361K (.142) (.173) 3.8 4.6 Model Designator MOV-07D470K MOV-07D391K MOV = Metal Oxide Varistor (.150) (.181) Disc Diameter 3.9 4.8 MOV-07D560K MOV-07D431K 07D = 7 mm (.154) (.189) Nominal Varistor Voltage 4.0 5.0 MOV-07D680K MOV-07D471K See Electrical Characteristics Table (.157) (.197) Multiplier of Voltage Digits 3.4 5.1 MOV-07D820K MOV-07D511K 0 = No multiplier (.134) (.201) 1 1 = nn * 10 3.6 5.4 MOV-07D101K MOV-07D561K Varistor Voltage Tolerance (.142) (.213) K = 10 % 3.8 5.8 Packaging MOV-07D121K MOV-07D621K (.150) (.228) Blank = Bulk 4.0 6.0 TR = Tape & Reel MOV-07D151K MOV-07D681K (.157) (.236) Examples: MOV-07D270K = 27 V, Bulk Pack MOV-07D331KTR = 330 V, Tape & Reel 3.2 6.2 MOV-07D181K MOV-07D751K (.126) (.244) Specications are subject to change without notice. 3.4 6.4 MOV-07D201K MOV-07D781K Users should verify actual device performance in their specic applications. (.134) (.252) The products described herein and this document are subject to specic legal disclaimers 3.5 6.8 as set forth on the last page of this document, and at MOV-07D221K MOV-07D821K (.138) (.268) www.bourns.com/docs/legal/disclaimer.pdf.
