Technical Data Sheet BRADY B-799 LASER PRINTABLE NYLON CLOTH LABEL TDS No. B-799 Effective Date: 14-Jan-2002 Description: Brady B-799 is a polyamide coated nylon cloth with a permanent acrylic pressure sensitive adhesive and a topcoat specifically formulated for laser or write-on printing. B-799 is designed for wiremarking and general labeling applications that require a permanent identification label. B-799 is not recommended for outdoor use. B-799 has good laser print resolution, good solvent resistance, smudge resistance, and moderate temperature performance. The specially formulated permanent adhesive will bond to many surfaces. It is recommended to test for permanency before use on any surface. Brady B-799 meets the requirements of a halogen-free material per DIN VDE 0472 part 815. (Statement based on review of product construction and confirmatory halogen content test run at an independent test laboratory.) Details: PHYSICAL PROPERTIES TEST METHODS AVERAGE RESULTS Thickness ASTM D 1000 -Substrate 0.0045 inch (0.115 mm) -Adhesive 0.0020 inch (0.051 mm) -Total 0.0065 inch (0.166 mm) Adhesion to: ASTM D 1000 45 oz/inch (50 N/100 mm) -Stainless Steel 20 minute dwell 80 oz/inch (88 N/100 mm) 24 hour dwell 35 oz/inch (39 N/100 mm) -Textured ABS 20 minute dwell 40 oz/inch (44 N/100 mm) 24 hour dwell 24 oz/inch (26 N/100 mm) -Polypropylene 20 minute dwell 24 oz/inch (26 N/100 mm) 24 hour dwell Tack ASTM D 2979 Polyken Probe Tack 29 oz (900 grams) 1 second dwell, 1 cm/sec separation Drop Shear PSTC-7 (except use 1/2 x 1 9 hours sample) Tensile Strength and Elongation ASTM D 1000 -Machine 80 lb/in (1400 N/100 mm), 50% Performance properties tested on B-799 printed with a Hewlett Packard LaserJet 5P laser printer. Printed samples of B-799 were laminated to aluminum and allowed to dwell 24 hours before exposure to the indicated environmental conditions. PERFORMANCE PROPERTIES TEST METHODS TYPICAL RESULTS Short Term High Service 5 minutes at 293F (145C) No visible effect to label at Temperature 145C. Slight shrinkage at 180C but label still functional. Long Term High Service 30 days at 193F (90C) No visible effect to label at 90C. Temperature Slight discoloration at 110C but label still functional. At 120C label is severely discolored. Low Service Temperature 30 days at -40F (-40 C) No visible effect Humidity Resistance 30 days at 100F, 95% R.H. No visible effect UV Light Resistance 30 days in UV Sunlighter 100 No visible effect 1 Weatherability ASTM G155, Cycle 1 Material wrinkled and embrittled 30 days in Xenon Arc Weatherometer Abrasion Resistance Taber Abraser, CS-10 grinding Slight topcoat removal and print wheels, 500 g/arm (Fed. Std. smear, but print remains legible 191A, Method 5306) to 150 cycles 1 B-799 is not recommended for long-term outdoor use. PERFORMANCE PROPERTY CHEMICAL RESISTANCE Samples printed with Hewlett Packard LaserJet 5P laser printer. Samples were laminated to aluminum panels and wrapped around a 12 AWG, TFE jacketed wire and allowed to dwell 24 hours prior to test. Test was conducted at room temperature except where noted. Testing consisted of 5 cycles of 10 minute immersions in the specified test fluid followed by a 30 minute period. After final immersion, samples rubbed 10 times with cotton swab saturated with test fluid. CHEMICAL REAGENT SUBJECTIVE OBSERVATION OF VISUAL CHANGE EFFECT TO LABEL HEWLETT PACKARD LASERJET 5P PRINTER STOCK EFFECT TO PRINT EFFECT TO PRINT WITHOUT RUB WITH RUB Methyl Ethyl Ketone Complete unwrap No visible effect Moderate print removal 1,1,1-Trichloroethane Complete unwrap No visible effect Moderate print removal Isopropyl Alcohol Complete unwrap No visible effect Complete print removal Mineral Spirits Complete unwrap No visible effect Comple te print removal NorthwoodsBuzz Saw Complete unwrap No visible effect Complete print removal Degreaser SAE 20 WT Oil at 70C No visible effect, label No visible effect No visible effect discoloration Mil 5606 Oil Slight unwrap, label No visible effect No visible effect stained red Speedi Kut Cutting Oil No unwrap, label No visible effect No visible effect 332 discoloration Gasoline Adhesive failure, label No visible effect Slight print removal discoloration Rust Veto 342 Moderate unwrap, label No visible effect Complete print removal discoloration Deionized Water No visible effect No visible effect No visible effect 3% Alconox Detergent No visible effect No visible effect No visible effect 5% Salt Solution No visible effect No visible effect No visible effect 10% Sodium Hydroxide Complete unwrap No visible effect No visible effect Solution 10% Sulfuric Acid No visible effect No visible effect No visible effect Solution
