VM800C Datasheet Version 1.2 Document Reference No.: FT 000844 Clearance No.: FTDI 345 FTDI Chip VM800C Datasheet Embedded Video Engine Credit Card Board General Purpose Multi Media Controller 1.1 Features 1 Introduction The VM800C is a development module for The VM800C utilises the FTDI FT800 FTDIs FT800, which is used to develop and Embedded Video Engine. Graphic, audio and demonstrate the functionality of the FT800 touch features of the FT800 can be accessed Embedded Video Engine, EVE. This module with the VM800C. For a full list of the FT800s behaves as an SPI slave, and requires a SPI features please see the FT800 datasheet. Master for proper micro-controller interfacing The VM800C has the following features: and system integration. Ready to use LCD module VM800C modules support 3 different LCD Part types with LCDs supporting resistive panel size options. Users can also connect to touch with pressure sensing. different LCD screens as long as they meet the FT800 technical specification and fit the On board LCD backlight LED Driver VM800C LCD connector. Supports mono audio output VM800C35A-D, 3.3/5V micro- controller adaptor card with 3.5 LCD On board audio power amplifier and micro touch display speaker VM800C43A-D, 3.3/5V micro- controller adaptor card with 4.3 LCD Flexible power supply. Powering the VM800C touch display using either a 2.1mm power jack , SPI master connector or via USB Micro-B port VM800C50A-D, 3.3/5V micro- controller adaptor card with 5.0 LCD 5 V tolerant buffers when used with a 5V SPI VMFT800C35A-N, 3.3/5V micro- Master. controller adaptor card, with 3.5 LCD connector but no display VMFT800C43A-N, 3.3/5V micro- controller adaptor card, with 4.3/5.0 LCD connector but no display Use of FTDI devices in life support and/or safety applications is entirely at the users risk, and the user agrees to defend, indemnify and hold harmless FTDI from any and all damages, claims, suits or expense resulting from such use. VM800C Datasheet Version 1.2 Document Reference No.: FT 000844 Clearance No.: FTDI 345 2 Ordering Information Note that the kits below require a 5V/1A power supply. It is NOT provided in the development kit, but is offered as an optional accessory, as is the USB to SPI cable, with the following part types: Part No. Description VM800C35A-N Credit Card Size VM800C module, supports 3.3/5v MCU Adapter Board, with FPC/FFC 54 LCD connector. No display is provided. VM800C43A-N Credit Card Size VM800C module, supports 3.3/5v MCU Adapter Board, with FPC/FFC 40 LCD. No display is provided. VM800C35A-D Credit Card Size VM800C module, supports 3.3/5v MCU Adapter Board, with FPC/FFC 54 LCD connector, 3.5 inch TFT LCD display panel preinstalled. Credit Card Size VM800C module, supports 3.3/5v MCU Adapter Board, with FPC/FFC 40 LCD connector, 4.3 inch TFT LCD display VM800C43A-D panel preinstalled. Credit Card Size VM800C module, supports 3.3/5v MCU Adapter Board, with FPC/FFC 40 LCD connector, 5.0 inch TFT LCD display VM800C50A-D panel preinstalled. VA-PSU-UK1 Accessory - UK Model 5V/1A USB Power Supply (Mfr JX-B0520C-1-B) VA-PSU-US1 Accessory - US Model 5V/1A USB Power Supply (Mfr JX-B0520B-1-B) VA-PSU-EU1 Accessory - EU Model 5V/1A USB Power Supply (Mfr JX-B0520A-1-B) Accessory - High Speed Micro USB to SPI adapter for BASIC boards VA800A-SPI based on FT232H MPSSE design VA-FC-1M-BKW Accessory - Flat USB A to Micro B Cable 1M- Black and White VA-FC-1M-BLW Accessory - Flat USB A to Micro B Cable 1M- Blue and White VA-FC-STYLUS1 Accessory - Resistive Touch Screen Pen Stylus Table 2-1 Ordering information 2 Copyright 2014 Future Technology Devices International Limited
