X-On Electronics has gained recognition as a prominent supplier of BM2257 Digital Multimeters across the USA, India, Europe, Australia, and various other global locations. BM2257 Digital Multimeters are a product manufactured by Brymen. We provide cost-effective solutions for Digital Multimeters, ensuring timely deliveries around the world.

BM2257 Brymen

Name: BM2257
Brand: Brymen
SKU: BM2257_Brymen
Availability: OutOfStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	BM2257
Manufacturer:	Brymen
Category:	Digital Multimeters
Description:	Digital multimeter; LCD; (6000); Bargraph: 60segm.40x/s; 5x/s
Datasheet:	BM2257 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 170.7699 ea
Line Total: USD 170.77

Availability - 0

MOQ: 1 Multiples: 1
Pack Size: 1

BM2257 More Buying Options & Price Grid(s)

Availability	Price	Buy Price	Quantity
0 Ship by Tue. 08 Apr to Thu. 10 Apr MOQ : 1 Multiples : 1	1 : USD 170.7699

Specifications

Manufacturer Brymen Brymen
Product Category Digital Multimeters Digital Multimeters
Kind Of Display Used LCD LCD
Power Supply b A ttery LR03 A A A 1 , 5 V x2 b A ttery LR03 A A A 1 , 5 V x2
Conform To The Norm EN 61010, CAT III 600V, CAT IV 300V EN 61010, CAT III 600V, CAT IV 300V
Illumination yes yes
Related Items BMH - 01, KITBRUA - 20X BMH - 01, KITBRUA - 20X
Standard Equipment test leads, K - type temperature probe, users manual test leads, K - type temperature probe, users manual
Measuring Instrument Features automatic power - off, HOLD function, auto and manual ranging, indicates incorrect connection of test leads, CREST: logging of extreme values MAX, MIN and MAX - MIN of voltage and current impulses > 0,8ms, MIN/MAX/REL function, contactless voltage detector, Autocheck function - automatic selection LoZ DCV, LoZ ACV, i Ω, logging of MAX, MIN automatic power - off, HOLD function, auto and manual ranging, indicates incorrect connection of test leads, CREST: logging of extreme values MAX, MIN and MAX - MIN of voltage and current impulses > 0,8ms, MIN/MAX/REL function, contactless voltage detector, Autocheck function - automatic selection LoZ DCV, LoZ ACV, i Ω, logging of MAX, MIN
Type Of Meter digital multimeter digital multimeter
Continuity Test acoustic indication, optical indication, 30Ω...480Ω acoustic indication, optical indication, 30Ω...480Ω
Sampling 5x/s 5x/s
Pollution Degree 2 2
Temperature Measuring Range - 40 To 99.9 C , 100 To 1000 C - 40 To 99.9 C , 100 To 1000 C
True Effective Value Measurement True RMS AC True RMS AC
Bargraph 60 segm. 40x/s 60 segm. 40x/s
Measurement AC voltage, DC voltage, temperature, frequency, capacitance, DC current, resistance, AC current AC voltage, DC voltage, temperature, frequency, capacitance, DC current, resistance, AC current
Dimensions W X H X D 80x161x50mm 80x161x50mm
Ac Current Measuring Range 10 A , 600 uA , 6 A , 60 mA , 600 mA , 6 mA 10 A , 600 uA , 6 A , 60 mA , 600 mA , 6 mA
Resistance Measuring Range 600 Ohms , 6 kOhms hms , 60 kOhms hms , 600 kOhms hms , 6 MOhms , 60 MOhms 600 Ohms , 6 kOhms hms , 60 kOhms hms , 600 kOhms hms , 6 MOhms , 60 MOhms
Dc Current Measuring Range 600 uA , 10 A , 60 mA , 600 mA , 6 A , 6 mA 600 uA , 10 A , 60 mA , 600 mA , 6 A , 6 mA
Dc Voltage Measuring Range 600 V , 6 V , 60 V , 600 mV , 60 mV 600 V , 6 V , 60 V , 600 mV , 60 mV
Ac Voltage Measuring Range 600 V , 6 V , 60 V , 600 mV , 60 mV 600 V , 6 V , 60 V , 600 mV , 60 mV
Frequency Measuring Range 10 Hz To 200 KHz 10 Hz To 200 KHz
Capacitance Measuring Range 10 MF , 200 uF , 2 MF , 20 uF , 2 uF , 200 nF , 20 nF 10 MF , 200 uF , 2 MF , 20 uF , 2 uF , 200 nF , 20 nF
Diode Test 0.3mA @3V 0.3mA @3V
Battery/ Rechargeable Battery battery LR03 AAA 1 , 5V x2 battery LR03 AAA 1 , 5V x2
Display Parameters (6000) (6000)
Frequency Measuring Accuracy (0.03 % + 3 digit) (0.03 % + 3 digit)
Capacitance Measuring Accuracy ± (1.5 % + 2 digit) , ± (1.5 % + 8 digit) @ 20 nF To 200 nF , ± (4.5 % + 10 digit) @ 10 MF ± (1.5 % + 2 digit) , ± (1.5 % + 8 digit) @ 20 nF To 200 nF , ± (4.5 % + 10 digit) @ 10 MF
Ac Current Measuring Accuracy (1 % + 5 digit) (1 % + 5 digit)
Dc Voltage Measuring Accuracy (0.2 % + 3 digit) @600 V , ± (0.3 % + 4 digit) @60 mV , ± (0.3 % + 4 digit) @600 mV , ± (0.3 % + 4 digit) @6 V , ± (0.4 % + 3 digit) @60 V (0.2 % + 3 digit) @600 V , ± (0.3 % + 4 digit) @60 mV , ± (0.3 % + 4 digit) @600 mV , ± (0.3 % + 4 digit) @6 V , ± (0.4 % + 3 digit) @60 V
Dc Current Measuring Accuracy (0.5 % + 5 digit) , ± (1 % + 5 digit) @6 A , ± (1 % + 5 digit) @10 A (0.5 % + 5 digit) , ± (1 % + 5 digit) @6 A , ± (1 % + 5 digit) @10 A
Ac Voltage Measuring Accuracy (0.7 % + 3 digit) , ± (1 % + 3 digit) (0.7 % + 3 digit) , ± (1 % + 3 digit)
Resistance Measuring Accuracy ± (0.5 % + 4 digit) , ± (0.7 % + 4 digit) @ (6 MOhms) , ± (2 % + 4 digit) @ (60 MOhms) ± (0.5 % + 4 digit) , ± (0.7 % + 4 digit) @ (6 MOhms) , ± (2 % + 4 digit) @ (60 MOhms)
Temperature Measurement Accuracy ± (0.3 % + 3 C) @ (100 C To 1000 C) , ± (1 % + 1 C) @ ( - 40 C To 99.9 C) ± (0.3 % + 3 C) @ (100 C To 1000 C) , ± (1 % + 1 C) @ ( - 40 C To 99.9 C)
