Sound, Alarm and Security Cable Electronics Composite Access Control Cable, Riser NEC Type CMR, UL, c(UL) Product Construction: Conductor: Stranded bare copper Jacket: PVC Temperature range: -20C to +60C Individual elements marked for application (see diagram below) Blue overall jacket Shields: Choice between all 4 elements shielded oVERAll CoMPoNENt INSUlA tIoN CAt Alog NoMINAl o .D. CoMPoNENt CoMPoNENt CoNDUCtoRS NoMINAl o.D . tHICkNESS or just the 3-pair shielded NUMBER INCH (MM) No. DESCRIPtIoNS ColoR CoDE INCH (MM) INCH (MM) Applications: Security systems 4 Cond, 18 AWG, White, Black, 1 0.180 (4.572) 0.008 (0.2032) Access control Shielded Red, Green Car d reader White & Green, 3 Pair, 22 AWG, Door control 2 Orange & Brown, 0.195 (4.593) 0.008 (0.2032) Shielded Red & Black REX 0.430 4ERS4S Power -limited controls 2 Cond, 22 AWG, 3 Red, Black 0.125 (3.175) 0.008 (0.2032) Shielded Compliances: NEC Article 800 Type CMR (UL), c(UL) 4 Cond, 22 AWG, White, Black, 4 0.145 (3.683) 0.008 (0.2032) RoHS Compliant Directive 2002/95/EC Shielded Red, Green Packaging: 4 Cond, 18 AWG, White, Black, 1 0.180 (4.572) 0.008 (0.2032) 500 and 1000 reels Unshielded Red, Green White & Green, 3 Pair, 22 AWG, 2 Orange & Brown, 0.195 (4.593) 0.008 (0.2032) Shielded Red & Black 4ERS1S 0.420 2 Cond, 22 AWG, 3 Red, Black 0.125 (3.175) 0.008 (0.2032) Unshielded 4 Cond, 22 AWG, White, Black, 4 0.145 (3.683) 0.008 (0.2032) Unshielded Red, Green Rex/Spare Jacket Color Coding & Component Application Door Contact Jacket Color Component Cable Type Application Gray 1 4 Conductor, 18 AWG Lock Power Orange 2 3 Pair, 22 AWG Card Reader White 3 2 Conductor, 22 AWG Door Contact Blue 4 4 Conductor, 22 AWG Rex/Spare Card Reader lock Power 133Electronics Sound, Alarm and Security Cable Multi-Conductor, Unshielded, Riser NEC Type CMR and/or CL3R Product Construction: Conductor: Stranded or solid bare copper per ASTM B-3, B-8 and B-286 Insulation: Pr emium-grade, coIor-coded S-R PVC Color code: See chart below Jacket: NoM. INSUlA tIoN NoM. JACkEt tHICkNESS WAll NoMINAl o.D. Pr emium-grade, gray PVC CAt Alog No. oF AWg CoND. NUMBER CoND. SIZE StRAND INCHES mm INCHES mm INCHES mm Sequential footage markings to facilitate installation 22 AWG CONDUCTORS T emperature range: -20C to +75C E1000S 2 22 Solid 0.007 0.20 0.015 0.38 0.118 3.00 Includes ripcord E1001S 4 22 Solid 0.007 0.20 0.015 0.38 0.126 3.20 Applications: E1002S 2 22 7/30 0.008 0.20 0.015 0.38 0.122 3.10 Power -limited control circuits E1003S 3 22 7/30 0.008 0.20 0.015 0.38 0.141 3.58 Wiring of the following systems: Intercom E1004S 4 22 7/30 0.008 0.20 0.015 0.38 0.141 3.66 Security E1006S 6 22 7/30 0.008 0.20 0.015 0.38 0.164 4.17 Audio Background music E1008S 8 22 7/30 0.008 0.20 0.015 0.38 0.180 4.57 Suggested voltage rating: 300 volts E1010S 10 22 7/30 0.008 0.20 0.015 0.38 0.212 5.38 Compliances: E1012S 12 22 7/30 0.008 0.20 0.015 0.38 0.219 5.56 NEC Article 725 Type CL3R (UL: 75C, 150V) 20 AWG CONDUCTORS NEC Article 800 Type CMR 2 20 7/28 0.007 0.18 0.015 0.38 0.134 3.40 E1022S (UL: 75C, 300V) 3 20 7/28 0.008 0.20 0.015 0.38 0.134 3.40 E1023S RoHS Compliant Directive 2002/95/EC 4 20 7/28 0.008 0.20 0.015 0.38 0.142 3.60 Califor nia State Fire Marshall Approved E1024S 18 AWG CONDUCTORS Packaging: Please contact Customer Service for E1030S 2 18 Solid 0.008 0.20 0.015 0.38 0.144 3.66 packaging and color options E1032S 2 18 7/26 0.009 0.23 0.015 0.38 0.156 3.96 E1033S 3 18 7/26 0.009 0.23 0.015 0.38 0.166 4.22 Color Code Chart E1034S 4 18 7/26 0.009 0.23 0.015 0.38 0.187 4.75 No. oF No. oF E1036S 6 18 7/26 0.008 0.20 0.015 0.38 0.225 5.72 CoND. ColoR CoND. ColoR E1038S 8 18 7/26 0.008 0.20 0.015 0.38 0.245 6.22 Black Orange 1 7 E1040S 10 18 7/26 0.008 0.20 0.015 0.38 0.282 7.16 Red Yellow 2 8 White Violet 3 9 E1041S 12 18 7/26 0.009 0.23 0.015 0.38 0.291 7.39 Green Gray 4 10 16 AWG CONDUCTORS Brown Pink 5 11 2 16 19/.0117 0.009 0.25 0.015 0.38 0.178 4.52 E1042S Blue Tan 6 12 3 16 19/.0117 0.009 0.25 0.015 0.38 0.193 4.90 E1043S 4 16 19/.0117 0.009 0.25 0.015 0.38 0.210 5.33 E1044S 14 AWG CONDUCTORS E1052S* 2 14 19/.0147 0.013 0.33 0.015 0.38 0.224 5.69 E1054S* 4 14 19/.0147 0.013 0.33 0.015 0.38 0.264 6.71 12 AWG CONDUCTORS 2 12 19/.0185 0.013 0.33 0.015 0.38 0.260 6.60 E1062S* 4 12 19/.0185 0.013 0.33 0.015 0.38 0.312 7.92 E1064S* * NEC CL3R only 134
