XPGBWT-BE-0000-00KE7 Cree

PRODUCT FAMILY DATA SHEET XLamp XP-G2 LEDs LED pictures and labels underneath are in a table XP-G2 Standard LED XP-G2 High Efficacy LED PRODUCT DESCRIPTION FEATURES The original XLamp XP-G2 LED pioneered a broad set of LED Available in white, outdoor white and 80, 85 and 90CRI white applications for the industry, including outdoor and area lighting, ANSIcompatible chromaticity bins and has since served as a preferred choice by manufacturers Broadcast color option at 5700K that require advanced output, efficacy and optical control. The Binned at 85C compact and proven 3.45mm XP platform has an excellent Maximum drive current: Standard: 1500mA, HE: 2000mA ecosystem of optics and system solutions available, enabling Low thermal resistance: Standard: 4C/W, HE: 3C/W lighting manufacturers to simplify their design process and Wide viewing angle: Standard: 120, HE: 125 shorten time to market. Unlimited floor life at 30C/85% RH Reflow solderable JEDEC JSTD020C XP-G2 LEDs are now available in two different White versions: Electrically neutral thermal path Standard and High Efficacy (HE). XPG2 Standard is the same RoHS and REACh compliant breakthrough product that enabled a broad set of new LED UL recognized component (E349212) applications for ceramic highpower LEDs. The new High Efficacy version extends this legacy with a dropin upgrade for existing designs optimized around XPG2 LEDs. XPG2 HE LEDs leverage Cree LEDs latest high-power chip technology to deliver 25 percent more light output via a higher maximum current of 2000mA and higher efficacy and lower thermal resistance. Cree LED / 4400 Silicon Drive / Durham, NC 27703 USA / +1.919.313.5330 / www.cree-led.com 2012-2022 Cree LED. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks, and CLD-DS51 the Cree LED logo is a trademark, of Wolfspeed, Inc. XLamp is a registered trademark of Cree LED. UL and the UL logo are registered trademarks of 1 REV 20 UL LLC. Other trademarks, product, and company names are the property of their respective owners and do not imply specific product and/or vendor endorsement, sponsorship or association. XLAMP XP-G2 LED TABLE OF CONTENTS Characteristics ....................................................................................................................................................................................................... 3 Order Codes Suggested for New Designs High Efficacy ................................................................................................................................... 4 Order Codes Suggested for New Designs Standard ........................................................................................................................................ 10 Flux Characteristics Broadcast Order Codes and Bins.................................................................................................................................... 14 Relative Spectral Power Distribution .................................................................................................................................................................. 15 Relative Flux vs. Junction Temperature .............................................................................................................................................................. 15 Electrical Characteristics High Efficacy ............................................................................................................................................................ 16 Electrical Characteristics - Standard .................................................................................................................................................................. 16 Relative Flux vs. Current High Efficacy ............................................................................................................................................................. 17 Relative Flux vs. Current Standard .................................................................................................................................................................... 17 Relative Chromaticity vs Current and Temperature High Efficacy .................................................................................................................. 18 Relative Chromaticity vs Current and Temperature - Standard ......................................................................................................................... 19 Typical Spatial Distribution High Efficacy ......................................................................................................................................................... 20 Typical Spatial Distribution - Standard ............................................................................................................................................................... 20 Thermal Design High Efficacy ........................................................................................................................................................................... 21 Thermal Design - Standard .................................................................................................................................................................................. 21 Performance Groups Luminous Flux............................................................................................................................................................... 22 Performance Groups Chromaticity .................................................................................................................................................................. 23 Standard Cool White Kits Plotted on ANSI Standard Chromaticity Regions .................................................................................................... 26 Standard Warm and Neutral White Kits Plotted on ANSI Standard Chromaticity Regions ............................................................................. 28 Standard Chromaticity Kits ................................................................................................................................................................................. 30 Bin and Order Code Formats ............................................................................................................................................................................... 31 Reflow Soldering Characteristics ........................................................................................................................................................................ 32 Notes .................................................................................................................................................................................................................... 33 Mechanical Dimensions ...................................................................................................................................................................................... 35 Tape and Reel ....................................................................................................................................................................................................... 37 Packaging ............................................................................................................................................................................................................. 38 Appendix Order Codes Not For New Designs .................................................................................................................................................. 39 2012-2022 Cree LED. The information in this document is subject to change without notice. Cree and the Cree logo are registered trademarks, and CLD-DS51 the Cree LED logo is a trademark, of Wolfspeed, Inc. XLamp is a registered trademark of Cree LED. UL and the UL logo are registered trademarks of 2 REV 20 UL LLC. Other trademarks, product, and company names are the property of their respective owners and do not imply specific product and/or vendor endorsement, sponsorship or association.
