Rectangular Style Analog Panel Meters UL Recognized - File E91015 Except for the Wattmeters & Frequency Meters Plastic case with Glass Window Calibration not affected when mounted on steel Three popular sizes: 2-1/2, 3-1/2, 4-1/2 For Specifications and Dimensions see the last pages Ordering Information Frequency, Self-Shielding Movement Not Model / Size and Catalog Number 2-1/2 3-1/2 4-1/2 Range Voltage Model 187 Model 87 Model 89 45-55 Hz 120V 35136 35142 35148 55-65 Hz 120V 35138 35144 35150 380-420 Hz 120V 35140 35146 35152 45-55 Hz 240V 35137 35143 35149 55-65 Hz 240V 35139 35145 35151 380-420 Hz 240V 35141 35147 35153 1 Rev. 08-14Rectangular Style Analog Panel Meters Ordering Information 4-20 mA Process Meters, Dial Indicates 0-100% Approx. Catalog Size Style Model Impedance (Ohms) No. 3-1/2 Rectangular 27 5.0 35023 4-1/2 Rectangular 29 5.0 35024 Wattmeters, Self Shielding Movement Not Maximum Model / Size and Catalog Number 2-1/2 3-1/2 4-1/2 Range Volts Amps Model 177 Model 77 Model 79 0-20 150 .400 < > < > 10714 0-75 150 1.0 10860 10650 10720 0-150 150 2.0 < > < > 10730 0-300 150 4.0 < > < > 10740 0-600 300 4.0 < > 10680 10750 0-750 150 10.0 10900 10690 10760 0-1500 300 10.0 10910 10700 10770 0-3000 300 20.0 10920 10710 10780 < > Available on special order 2 Rev. 08-14
