1N5408 Diodes Incorporated

1N5400-1N5408 1N5400 - 1N5408 Features 3.0 ampere operation at T = 75C A with no thermal runaway. High current capability. Low leakage. DO-201AD COLOR BAND DENOTES CATHODE General Purpose Rectifiers Absolute Maximum Ratings* T = 25C unless otherwise noted A Symbol Parameter Value Units 5400 5401 5402 5403 5404 5405 5406 5407 5408 V Maximum Repetitive Reverse 50 100 200 300 400 500 600 800 1000 V RRM Voltage I Average Rectified Forward Current, 3.0 A F(AV) .375 lead length T = 75C A I Non-repetitive Peak Forward Surge FSM Current 200 A 8.3 ms Single Half-Sine-Wave Storage Temperature Range -55 to +150 T C stg T Operating Junction Temperature -55 to +150 C J *These ratings are limiting values above which the serviceability of any semiconductor device may be impaired. Thermal Characteristics Symbol Parameter Value Units P Power Dissipation 6.25 W D Thermal Resistance, Junction to Ambient 20 R C/W . JA Electrical Characteristics T = 25C unless otherwise noted A Symbol Parameter Device Units 5400 5401 5402 5403 5404 5405 5406 5407 5408 V Forward Voltage 3.0 A 1.2 V F I Maximum Full Load Reverse rr 0.5 mA Current, Full Cycle T = 105C A I Reverse Current rated V R R 5.0 uA T = 25C A 500 uA T = 100C A C Toatal Capacitance T 30 pF V = 4.0 V, f = 1.0 MHz R . 2001 Fairchild Semiconductor Corporation 1N5400-1N5408, Rev C1, June 2006 1N5400-1N5408 General Purpose Rectifiers (continued) Typical Characteristics 4 100 3 10 5 T = 25 C J 9.5mm LEAD LENGTH Pulse Width = 200S 1% Duty Cycle 2 1 1 0.1 0 25 50 75 100 125 150 175 200 0.01 0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 Ambient Temperature C Forward Voltage, V V F Figure 1. Forward Current Derating Curve Figure 2. Forward Voltage Characteristics 200 100 160 10 120 80 T = 25 C A 1 T = 105 C A 40 0 0.1 12 5 10 20 50 100 0 20406080 100 120 140 Number of Cycles at 60Hz Percent of Rated Peak Reverse Voltage % Figure 3. Non-Repetitive Surge Current Figure 4. Reverse Current vs Reverse Voltage 100 50 10 5 1 0.1 1 5 10 50 100 Reverse Voltage, V V R Figure 5. Total Capacitance . 2001 Fairchild Semiconductor Corporation 1N5400-1N5408, Rev C1, June 2006 Peak Forward Surge Current, I A Average Rectified Forward Current, I A FSM F Total Capacitance, C pF T Reverse Current, I uA Forward Current, I A R F
