SBRT25M50SLP Green 25A TrenchSBR TRENCH SUPER BARRIER RECTIFIER POWERDI 5060 Product Summary Features and Benefits V (MAX) (V) I (mA) F R(MAX) Reduced low forward voltage drop (V ) Better efficiency and F V (V) I (A) RRM O +25C +25C cooler operation. 50 25 0.55 0.12 Reduced high temperature reverse leakage Increased reliability against thermal runaway failure in high temperature operation. Less than 1.1mm package profile ideal for thin applications. Lead-Free Finish RoHS Compliant (Notes 1 & 2) Halogen and Antimony Free Green Device (Note 3) Qualified to AEC-Q101 Standards for High Reliability Description and Applications Mechanical Data Packaged in the compact thermally efficient POWERDI5060-8 Case: POWERDI5060-8 package, the SBRT25M50SLP provides low V and excellent reverse Case Material: Molded Plastic, Green Molding Compound F leakage stability at high temperatures. It is ideal for use as a rectifier, UL Flammability Classification Rating 94V-0 freewheel diode or blocking diode in: Moisture Sensitivity: Level 1 per J-STD-020 Terminals: Finish - Matte Tin Annealed over Copper Leadframe. DC-DC Converters Solderable per MIL-STD-202, Method 208 AC-DC Adaptors Polarity: See Below Weight: 0.097 grams (Approximate) POWERDI5060-8 Top View Bottom View Pin A 1 A A A Bottom View C C C C Ordering Information (Note 4) Part Number Case Packaging SBRT25M50SLP-13 POWERDI5060-8 2,500/Tape & Reel Notes: 1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied. 2. See SBRT25M50SLP Maximum Ratings ( T = +25C, unless otherwise specified.) A Single phase, half wave, 60Hz, resistive or inductive load For capacitance load, derate current by 20%. Characteristic Symbol Value Unit Peak Repetitive Reverse Voltage V RRM Working Peak Reverse Voltage 50 V V RWM DC Blocking Voltage V RM Average Rectified Output Current I 25 A O Non-Repetitive Peak Forward Surge Current 8.3ms I 220 A FSM Single Half Sine-Wave Superimposed on Rated Load Thermal Characteristics Characteristic Symbol Value Unit Typical Thermal Resistance Junction to Ambient (Note 5) 11 C/W R JA Typical Thermal Resistance Junction to Case (Note 5) 1 C/W R JC Operating and Storage Temperature Range T T -55 to +150 C J, STG Electrical Characteristics ( TA = +25C, unless otherwise specified.) Characteristic Symbol Min Typ Max Unit Test Condition 0.42 0.47 I = 12.5A, T = +25C F J Forward Voltage Drop V V F 0.55 IF = 25A, TJ = +25C 0.04 0.12 V = 50V, T = +25C R J Leakage Current (Note 6) I mA R 50 V = 50V, T = +125C R J Notes: 5. Test with FR4 substrate 2oz, 2-inch sq. double side copper + additional Aluminum heatsink 50mm*50mm*23mm. 6. Short duration pulse test used to minimize self-heating effect. SBRT and POWERDI are registered trademarks of Diodes Incorporated. 2 of 5 February 2015 SBRT25M50SLP Diodes Incorporated www.diodes.com Document number: DS36941 Rev. 3 - 2 NEW PRODUCT
