A38 Diplomat

A38 / SMA38 Cascadable Amplifier Rev. V3 10 to 2000 MHz Features Product Image HIGH OUTPUT POWER: +19 dBm (TYP.) HIGH THIRD ORDER I.P.: +30 dBm (TYP.) WIDE BANDWIDTH: 10-2000 MHz Description The A38 RF amplifier is a discrete thin film hybrid design, which incorporates the use of thin film manufacturing processes for accurate performance and high reliability. This single stage bipolar transistor feedback amplifier design displays impressive performance over a broadband frequency range. An active DC biasing network is used for temperature-stable performance, in addition to an RF Choke, used for power supply decoupling. Both TO-8 and Surface Mount packages are hermetically sealed, and MIL-STD-883 environmental screening is available. Ordering Information Part Number Package A38 TO-8 SMA38 Surface Mount CA38 ** SMA Connectorized ** The connectorized version is not RoHs compliant. Electrical Specifications: Z = 50, V = +15 V Absolute Maximum Ratings 0 CC DC Parameter Absolute Typical Guaranteed Maximum Parameter Units 25C 0 to 50C -54 to +85C* Storage Temperature -62C to +125C Frequency MHz 5-2050 10-2000 10-2000 Case Temperature 125C DC Voltage +17 V Small Signal Gain (min) dB 9.5 8.5 7.5 Continuous Input Power +17 dBm Gain Flatness (max) dB 0.4 0.7 1.0 Short Term Input power 100 mW (1 minute max.) Reverse Isolation dB 15 Peak Power (3 sec max.) 0.5 W Noise Figure (max) dB 6.5 7.7 8.2 S Series Burn-In 125C Power Output Temperature (case) dBm 19.0 18.0 17.5 1 dB comp. (min) Thermal Data: V = +15 V CC DC IP3 dBm +30 Parameter Rating IP2 dBm +45 Thermal Resistance 119C/W Second Order Harmonic IP dBm +52 jc Transistor Power Dissipation P 0.659 W d VSWR Input / Output (max) 1.8:1 / 1.8:1 2.2:1 / 2.2:1 2.3:1 / 2.3:1 Junction Temperature Rise 79C DC Current 15 Volts (max) mA 65 69 72 Above Case T jc o o 11 1 * Over temperature performance limits for part number CA38, guaranteed from 0 C to +50 C only. M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. Visit www.macom.com for additional data sheets and product information. For further information and support please visit: A38 / SMA38 Cascadable Amplifier Rev. V3 10 to 2000 MHz * Typical Performance Curves at +25C Outline Drawing: TO-8 WEIGHT: 1 gram (0.04 oz.) max * Outline Drawing: Surface Mount WEIGHT: 1 gram (0.04 oz.) max * Outline Drawing: SMA Connectorized WEIGHT: 19 grams (0.67 oz.) max 22 Dimensions are inches (millimeters) 0.015 (0.38) unless otherwise specified. 2 M/A-COM Technology Solutions Inc. (MACOM) and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice. Visit www.macom.com for additional data sheets and product information. For further information and support please visit:
