INTERLOCK SwITC 100 SERIES TM Non-Contact Interlock/Position Switch 115 GuardSwitch Applications Packaging Industry Emergency Vehicles Farm Equipment Position Sensing Waste Compactors General Specifications Enclosure Nylon 6/6 2.54 0.75 Temperature Range -40F to 180F (-40C to 80C) 6.45cm 1.91cm 0.41 1.73 Environmental Hermetically Sealed Contact Switch 1.04cm 4.39cm 0.31 Encapsulated in Polyurethane 0.63 0.79cm 1.60cm NEMA Rating 1, 2, 3, 4, 4X, 5, 6, 12, 12K Protection Class IP 67 2.11 0.22 0.19 Response Time 1msec 10 msec (150VA) 5.36cm 0.56cm 0.48cm Life Cycles 100,000 Under Full Load Up to 200,000,000 Under Dry Circuit Lead Types/O.D. 18/2 SJTOW (K) / 0.30 (0.76cm) sensing face Switch 18/3 SJTOW (K) / 0.33 (0.84cm) 18/4 SJTOW (K) / 0.34 (0.86cm) UL/CSA All Models Actuator sensing face File E 1229 42 LR8917 S Order Information Electrical Specifications h 1 2 Contact Load Rating Switching Voltage, Max. Switching Current, Max. Contact Sense Range Break Range Lead Part Number Config. AC DC AC DC AC DC Resistance Nominal Nominal Length 3 3 115-3Y-12K N.C. 100VA 84W 120V( 0.8A) 28V( 3.0A) 3.0A ( 34V) 3.0A ( 28V) 1.0 Ohms 0.7 (1.8cm) 1.2 (3.0cm) 12 (3.6m) 3 3 115-4Y-06K SPDT 100VA 84W 120V( 0.8A) 28V( 3.0A) 3.0A ( 34V) 3.0A ( 28V) 1.0 Ohms 0.7 (1.8cm) 1.2 (3.0cm) 6 (1.8m) 3 3 115-4Y-12K SPDT 100VA 84W 120V( 0.8A) 28V( 3.0A) 3.0A ( 34V) 3.0A ( 28V) 1.0 Ohms 0.7 (1.8cm) 1.2 (3.0cm) 12 (3.6m) 115-6Y-06K N.O. 25VA 25W 120V( 0.2A) 120V( 0.2A) 0.7A ( 35V) 1.0A ( 25V) 0.2 Ohms 1.0 (2.5cm) 2.0 (5.1cm) 6 (1.8m) 115-6Y-12K N.O. 25VA 25W 120V( 0.2A) 120V( 0.2A) 0.7A ( 35V) 1.0A ( 25V) 0.2 Ohms 1.0 (2.5cm) 2.0 (5.1cm) 12 (3.6m) 3 3 115-7Y-06K N.O. 100VA 84W 120V( 0.8A) 28V( 3.0A) 3.0A ( 34V) 3.0A ( 28V) 1.0 Ohms 0.7 (1.8cm) 1.2 (3.0cm) 6 (1.8m) 3 3 115-7Y-12K N.O. 100VA 84W 120V( 0.8A) 28V( 3.0A) 3.0A ( 34V) 3.0A ( 28V) 1.0 Ohms 0.7 (1.8cm) 1.2 (3.0cm) 12 (3.6m) 4 115-8Y-06K N.O. 150VA NA 120V( 1.25A) NA 1.25A( 120V) NA NA 1.0 (2.5cm) 1.5 (3.8cm) 6 (1.8m) 4 115-8Y-12K N.O. 150VA NA 120V( 1.25A) NA 1.25A( 120V) NA NA 1.0 (2.5cm) 1.5 (3.8cm) 12 (3.6m) 5 4 115-8Y-06K-SER25 N.O. 150VA NA 120V( 1.25A) NA 1.25A( 120V) NA NA 1.0 (2.5cm) 1.5 (3.8cm) 6 (1.8m) 5 4 115-8Y-12K-SER25 N.O. 150VA NA 120V( 1.25A) NA 1.25A( 120V) NA NA 1.0 (2.5cm) 1.5 (3.8cm) 12 (3.6m) 115-6Y-06K-D6 2 N.O. 25VA 25W 120V( 0.2A) 100V( 0.2A) 0.7A ( 35V) 1.0A ( 25V) 0.2 Ohms 1.0 (2.5cm) 2.0 (5.1cm) 6 (1.8m) 115-6Y-12K-D6 2 N.O. 25VA 25W 120V( 0.2A) 100V( 0.2A) 0.7A ( 35V) 1.0A ( 25V) 0.2 Ohms 1.0 (2.5cm) 2.0 (5.1cm) 12 (3.6m) 115-Y Actuator Only Warning Each electrical rating is an individual maximum and cannot be exceeded 1 Configuration with actuator away from the switch 2 Proximity of ferrous materials usually reduces sense range typically by 50%. The shape and type of material cause a wide diversity of effects. Testing is required to determine actual sense range for specific applications. 3 Rated at 3.0A for 6,000 cycles only. Other ratings are at 100,000 cycles. 4 Can withstand inrush surge up to 4 amps. Voltage Drop 1.5V, minimum switch current of 30mA. 5 SER25 Maximum 25 switches in series , triac output. 1-800-336-4206 www.edwardssignaling.com 47 X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for edwards signaling manufacturer: Other Similar products are found below : E102A 105XBRIRBA120A 874-G5 50LMP-40W 92-ST 125LEDFR120A 115-Y 113LMP-10W 115-6Y-06K 115-7Y-06K 115-6Y-12K 1085T-G
