M.443 CH Handles technical informations Material Glass-fibre reinforced polyamide based (PA) technopolymer. Resistant to solvents, oils, greases and other chemical agents. Colour RAL 9005 black, RAL 2004 orange, RAL 7031 grey, RAL 3000 red, matte finish.Assembly Through holes for cylindrical-head screws with hexagon socket. Execution M.443/180-CH: slotted assembly holes for fitting hole centres from 149 to 152 mm. Technical data Tensile stress and impact strength: F1, F2, L1 and L2 values reported in the table are the result of breaking tests carried out with the appropriate dynamometric equipment under the test conditions shown in the figure with ambient temperature. Standard Elements F F L L Main dimensions Mounting holes Weight 1 2 1 2 Black Orange Grey Red l d h h Code Description L f h B l d N N J J g 1 1 1 2 37001 37002 37004 - M.443/110-CH* 109 93.50.5 38 6 21 74 6.5 10.5 7 13 3500 2500 15 8 26 37111 - - - M.443/140-6-CH* 137 1171 41 7 26 93 6.5 10.5 6 15 4500 2500 20 13 44 37101 37102 37104 37105 M.443/140-8-CH* 137 1171 41 7 26 93 8.5 13.5 8.5 15 4500 2500 20 13 42 37145 - - - M.443/145-CH* 142 1201221 41 7 26 100 8.5 13.5 8.5 15 3700 2500 25 14 44 37151 37152 37154 - M.443/150-CH* 150 1321 45 7 27 108 8.5 13.5 8.5 16 3500 2500 27 14 47 37191 37192 37193 - M.443/180-CH* 172 1491521 47 7 27 125 8.5 13.5 8.5 17 3000 2600 27 15 53 37201 37202 37204 37205 M.443/200-CH* 196 1791 50 7.5 28 151 8.5 13.5 8.5 17 2800 2700 28 17 70 37251 37252 37254 - M.443/260-CH* 260 2351 54 8.5 30 201 10.5 16.5 10.5 20 3200 3500 30 22 118 * Complete the code and the description of the standard item neededby addingone of the availablecolour listed in the code column. ELESA and GANTER models all rights reserved in accordance with the law. Always mention the source when reproducing our drawings.
