8783 Elesa & Ganter

1. Mounts: Elesa & Ganter mounts are available in a wide range of sizes for surface and recessed installation. The Elesa & Ganter 8783 series include various mounting hardware to suit a range of applications, such as threaded studs, threaded rods, and screws. 2. Body: The 8783 series features a robust, die-cast zinc body with zinc or stainless steel cover and is available in a grey or black finish. A sealed polyamide O-ring at the top of the body provides help to ensure an increased IP study level. 3. Fork and Collet: The fork and stainless steel collet of the 8783 series provide an improved protection level and an over-tightening stop for the shaft, ensuring the desired tightness of the connection. 4. Handle: For manual operation, the 8783 series includes a lever handle for easy and secure operation. It has been designed for maximum ergonomics and a comfortable feel when closing/opening the clamping jaw. 5. Jaw: The main contact element of the 8783 series is the two-part jaw, which combines the serrated teeth together with a carbon steel plate. It provides both a high grip level and a good torque transfer. 6. Jaw Sealing: To prevent leakage a one-piece seal is provided between the fork and the jaw. This helps to create a reliable and tight connection within the clamping system. 7. Clamping Forces: The 8783 series can be supplied with several different sizes of screws, bolts, and clamping forces. 8. Markings: Each product in the 8783 series is marked with clear information, such as dimensions, peak clamping force and torque setting. This ensures that our customers can easily identify the necessary components for the application.
