1 / 8 / 2 2 , 7 : 1 7 P M T y p e 4 X P o l y e s t e r J u n c t i o n B o x ( P J S e r i e s ) - H a m m o n d M f g . Quality Products. Service Excellence. Type 4X Polyester Junction Box PJ Series Continuous Hinge Door with Twist/Snap Latches Application Designed for use as instrument enclosures, electric, hydraulic or pneu matic control housings, electrical junction boxes or terminal wiring enclosures. Provides outstanding insulation and protection where equipment may be hosed down or be very wet. Ideal in applications with high temperatures or highly corrosive environments. Standards UL 508A Type 1, 2, 3, 4, 4X, 12, & 13 CSA Type 1, 2, 3, 4, 4X, 12, & 13 Complies with NEMA Type 1, 2, 3, 4, 4X,12, & 13 IEC 60529, IP66 Construction Molded fiberglass polyester enclosure with matching cover is easily punched, cut, or drilled. Enhanced UV inhibitors protect against outdoor weathering. 10-32 threaded brass inserts are provided for optional inner panel or terminal kit mounting. Mounting hardware is included. Stainless steel butterfly typetwist latc door fasteners. Stainless steel draw typesnap latc door fasteners. Door fasteners include a provision for padlocking. Twist latch enclosures are available with bonded polycarbonate viewing windows. Door is supported with a continuous stainless steel hinge. Captive oil resistant gasket provides a positive seal. Threaded brass inserts are provided for mounting feet to the rear of the enclosure. Stainless steel mounting brackets and hardware are provided for mounting to the rear of the enclosure. Operating temperatures between 130C and -40C (266F to -40F). Impact index of 6.78J (5 ft/lb). For corrosion resistance information, please refer to table in the Technical Information section. Finish Fiberglass polyester material has a gray finish. Optional inner panels are available in white powder coated finished steel, unfinished aluminum, or Fiberglass. Accessories Additional Inner Panels Terminal Kit Assemblies Pole Mounting Kit PJ/PJU/PCJ Replacement Hardware Kits Window Kits PJ Stainless Replacement Mounting Feet h t t p s : / / w w w . h a m m f g . c o m / e l e c t r i c a l / p r o d u c t s / n o n - m e t a l l i c / p j l 1 / 21 / 8 / 2 2 , 7 : 1 7 P M T y p e 4 X P o l y e s t e r J u n c t i o n B o x ( P J S e r i e s ) - H a m m o n d M f g . Climate Control General Accessories Snap Latch Enclosure Optional Inner Panel Part No. H W D H W Part No. PJ664L 6.10 6.10 4.18 4.88 4.88 14R0505 PJ864L 8.00 6.12 4.13 6.75 4.88 14R0705 PJ1084L 10.13 8.26 4.13 8.75 6.88 14R0907 PJ1086L 10.13 8.26 6.13 8.75 6.88 14R0907 PJ12106L 12.13 10.26 6.13 10.75 8.88 14R1109 PJ12124L 12.13 12.13 4.13 10.75 10.88 14R1111 PJ12126L 12.13 12.13 6.13 10.75 10.88 14R1111 PJ14126L 14.13 12.26 6.13 12.75 10.88 14R1311 PJ16148L 16.27 14.40 8.13 14.75 12.88 14R1513 PJ18168L 18.40 16.40 8.13 16.88 14.88 P1868 PJ20168L 20.00 16.00 8.13 18.44 14.44 P2068 Alternative inner panel options also available. Twist Latch Enclosure Optional Inner Panel Part No. H W D H W Part No. PJ664T 6.10 6.10 4.18 4.88 4.88 14R0505 PJ864T 8.00 6.12 4.13 6.75 4.88 14R0705 PJ1084T 10.13 8.26 4.13 8.75 6.88 14R0907 PJ1086T 10.13 8.26 6.13 8.75 6.88 14R0907 PJ12106T 12.13 10.26 6.13 10.75 8.88 14R1109 PJ14126T 14.13 12.26 6.13 12.75 10.88 14R1311 PJ16148T 16.27 14.40 8.13 14.75 12.88 14R1513 PJ18168T 18.40 16.40 8.13 16.88 14.88 P1868 PJ20168T 20.00 16.00 8.13 18.44 14.44 P2068 Alternative inner panel options also available. Data subject to change without notice 2022. Hammond Manufacturing Ltd. All rights reserved. h t t p s : / / w w w . h a m m f g . c o m / e l e c t r i c a l / p r o d u c t s / n o n - m e t a l l i c / p j l 2 / 2
