HARTING PROFINET Type A Cable 4-wire Cat. 5 PVC PROFINET Type A Cable 4-wire, Cat. 5, PVC Advantages General S ui t a b l e for PRO FINE T c a b lin g Cate g or y This data cable is suitable for PROFINET cabling 5 / Cl a s s D ac c or d in g to ISO / IEC 11 8 01 according to type A in industrial premises and ar- re s p e c t i ve l y EN 5 0 173 -1 an d ISO / IEC 24 70 2 ea s. It i s u s ea b l e for fi x in s t all at i o n. T h e c ore i s respectively EN 50 173-3 fitted with 4 wires twisted to quad that allows the transmission of Fast Ethernet 10/100Mbit/s. Ca p a b l e for fi x in s t all at i o n It is designed for fast assembling with the easy- stripping tool and can be assembled with all A p p li c a b l e for in d u s tr i al pre m i s e s HARTING 4-pole RJ45 connectors. Ro H S c o nfor m, U L li s te d, fl am e ret ar d ant Identification Part number Drawing PROFINET Type A Cable 4-wire, Cat. 5, PVC 20 m r ing 09 45 600 0130 50 m ring 09 45 600 0140 100 m ring 09 45 600 0100 500 m reel 09 45 600 0110 Wire: Solid bare copper AWG 22/1 Insulation: PE 1.5 mm Inner sheath: Polyvinylchlor ide (PVC) Ov erall screen: Aluminate foil over lapped, tinned copper wire braid, braid coverage about 90% Outer sheath: Polyvinylchlor ide (PVC), flame retardant Color code: wh, ye, bu, or Color of inner sheath: white Color of outer sheath: green, RAL 6018 Overall diameter : 6.3 mm 6.7 mm All data given are in line with the actual state of art and therefore not binding. HARTING reserves the right to modify designs without giving the relevant reasons. 09 45 600 01X0HARTING PROFINET Type A Cable 4-wire Cat. 5 PVC Technical Characteristics Performance Categor y 5 according to EN 50 288-2-1:2003, IEC 61 156-5:2002 Mechanical Characteristics Minimal bending radius Repeated bending: 7,5 x diameter Single bending: 3 x diameter Tensile strength max. 150 N Electrical Characteristics at 20 C Transfer impedance 10 MHz 10 mOhm/m Conductor resistance max. 115 Ohm/km Insulation resistance min. 500 MOhm*km Velocity of propagation 5.3 ns/m Characteristic impedance at 100 MHz 100 Ohm 5 Ohm Test voltage (wire/wire/screen r ms 50 Hz 1min) 2000 V Chemical Characteristics Flame retardant IEC 60 332-1-2 Free of hazardous substances RoHS 2002/95/EG Limited oil resistance Sunlight resistant UL 1581 Sec. 1200 Thermal Characteristics Permissible temperature range fixed operation 40 C to + 75 C flexible operation 20 C to + 60 C Printing HAR TING INDUSTRIAL ETHERNET STANDARD CABLE CAT 5 PLUS * 22AWG (SHIELDED) (UL) E333432 VERI- FIED CAT 5E CMG 75C or PLTC or AWM 21694 600V FT4 SUN RES * 094560001000100Meter mar kier un *Jahr/ AuftragsnummeHARTING-LOG Weight about 66 kg/km All data given are in line with the actual state of art and therefore not binding. HARTING reserves the right to modify designs without giving the relevant reasons. 09 45 600 01X0
