X-On Electronics has gained recognition as a prominent supplier of SDP8436-3 Phototransistors across the USA, India, Europe, Australia, and various other global locations. SDP8436-3 Phototransistors are a product manufactured by Honeywell. We provide cost-effective solutions for Phototransistors, ensuring timely deliveries around the world.

SDP8436-3 Honeywell

Name: SDP8436-3
Brand: Honeywell
SKU: SDP84363_Honeywell
Availability: OutOfStock
Rating: 5 (11 reviews)

SDP8436-3 electronic component of Honeywell

Images are for reference only
See Product Specifications

Part No.	SDP8436-3
Manufacturer:	Honeywell
Category:	Phototransistors
Description:	PHOTOTRANSISTOR, SIDE VIEW
Datasheet:	SDP8436-3 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

5: USD 1.6688 ea
Line Total: USD 8.34

Availability - 0

MOQ: 5 Multiples: 1
Pack Size: 1

SDP8436-3 More Buying Options & Price Grid(s)

Availability	Price	Buy Price	Quantity
0 Ship by Fri. 07 Feb to Thu. 13 Feb MOQ : 5 Multiples : 1	5 : USD 1.6688 25 : USD 1.3322 100 : USD 1.224 250 : USD 1.1824 500 : USD 1.0968 1000 : USD 0.9687

Specifications

Manufacturer Honeywell Honeywell
Product Category Phototransistors Phototransistors
Rise Time 10?s 10?s
Wavelength Typ - -
Power Consumption 100 mW 100 mW
Viewing Angle 18 18
Transistor Case Style Side Looking Side Looking
No Of Pins 2 2
Packaging Each Each
Msl - -
Svhc No Svhc (17 - Dec - 2014) No Svhc (17 - Dec - 2014)
Angle Of Half Sensitivity 18 18
Current Ic Typ 17.5 mA 17.5 mA
External Depth 4.29 mm 4.29 mm
External Length / Height 3.3 mm 3.3 mm
External Width 4.57 mm 4.57 mm
Fall Time Tf 10?s 10?s
Lead Spacing 2.54Mm 2.54Mm
Operating Temperature Max 85 C 85 C
Operating Temperature Min - 40 C - 40 C
Operating Temperature Range - 40 C To + 85 C - 40 C To + 85 C
Peak Spectral Response Wavelength 880 nm 880 nm
Sensitivity Mw / Cm Max 17.5@1 17.5@1
Sensitivity Mw / Cm Min 7.0@1 7.0@1
Transistor Polarity Npn Npn
Transistor Type Photo Photo
Voltage Vcc 5 V 5 V

We are delighted to provide the SDP8436-3 from our Phototransistors category, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the SDP8436-3 and other electronic components in the Phototransistors category and beyond.
