accEssoRiEs
accEssoRiEs
PYR 5008 and 7511 resistors
For voltage balancing and/or discharge of electrolytic capacitors
Fits capacitor diameters 5090 mm
Easy to mount
application Basic dEsign
Voltage balancing of series connected The PYR resistors are wire wound on a are made of stainless steel and connected
electrolytic can type capacitors and/or dis- ceramic core and coated with high tem- by two point spot welding.
charge purposes. perature silicone. The mounting brackets
spEciFication
standards CECC 40201, MIL -R26E
Resistance range 1047 k W
Resistance tolerance +/ 5%
Rated voltage 700 VDC acc. to CECC 40201-003
t emperature range 55 to +105C
dimensions tablep YR (mm)
t ype a l d m B H s d Weight
1 2 1 1 max approx (g)
PYR 5008 22.0* 40 10.6 6.3 21 15 0.4 10 9
PYR 7511 32.0 50 10.6 6.3 21 15 0.4 10 11
* Brackets are adjustable up to A = 28.5
article tablep YR
article code R (k W)* p (W) p (W) p (W) Fits cap.
max max max
40c 85c 105c diameter
PYR 5008 / 47 47 10 8 7 5065
PYR 7511 / 10 10 13 11 10 7590
PYR 7511 / 18 18 13 11 10 7590
PYR 7511 / 27 27 13 11 10 7590
PYR 7511 / 47 47 13 11 10 7590
* Other R values on request
150accEssoRiEs
Mounting dataF oR tHE accEssoRiEs
nYlon cap nuts Mounting Max chassis Width creepage t est voltage Max tightening c apacitor
hole thickness of jaws distance 5060 Hz torque diameter
mm (min) (mm) (mm) (mm) 1 min (KVac) (nM) (mm)
17.5 5 17 4.5 2.5 3 = 35
pYB 7033, M8
17.5 5 19 2.5 2,5 8 > 35
pYB 7026, M12
22.5 5 19 5 2.5 8 > 35
pYB 7041, M12
30.5 5 19 9 4 8 > 35
pYB 7042, M12
s cREWs WasHERs Max
stainlEss stEEl stainlEss stEEl M l d d t s tightening
torque (nM)
D
t
d
M5 10 8.7 5.1 1.2 10 3
pYc 7150, M5
pYc 6750, M5
D
t
d
M6 12 11.1 6.1 1.6 12 5 *
pYc 6751, M6* pYc 6756, M6*
* M6 and M5 (max connector thickness 3 mm incl. washer)
151
