Product Information Page 1 of 6 LFLEX CLASSIC 110 Valid: 04.04.2011 Product Description Space saving installation due to small cable diameters High electrical performance due to 4kV test voltage Application range Plant engineering and construction Industrial machinery Air conditioning installations Power station Stage technique Fixed installation as well as occasional flexing at free, non-continuously recurring movement without tensile load Dry or damp interiors under medium mechanical load conditions Benefits Space saving installation due to small cable diameters High electrical performance due to 4kV test voltage Design Fine strands of bare copper wires PVC insulation LAPP P8/1 Cores twisted in layers PVC outer sheath, grey (RAL 7001) Approvals (Norm references) Remark: A RoHS-non-compliant version is marketed under LFLEX 110 with VDE-REG.-Nr. 8067. To order this, please add appendix to the below stated part numbers. This does not affect the above given further technical data or description. Product features Flame retardant according to IEC 60332-1-2Product Information Page 2 of 6 LFLEX CLASSIC 110 Valid: 04.04.2011 Good chemical resistance see Appendix T1 Technical Data Core identification code Test voltage Black with white numbers acc. to VDE 0293 4000 V Specific insulation resistance Protective conductor > 20 GOhm x cm G = with protective conductor GN/YE Conductor stranding X = without protective conductor Fine wire in accordance to VDE 0295 Class 5 / IEC Range of temperature 60228 Class 5 Occasional flexing: -5C up to +70C Minimum bending radius Fixed installation: -40C up to +80C Occasional flexing: 15 x cable diameter VDE tested Fixed installation: 4 x cable diameter VDE Reg. No. 7030 for following sizes: up to 2,5 mm: 2 - Rated voltage 65 cores starting at 4 mm: 2 - 7 cores U0/U: 300/500 V Article List Number Part Outer Copper Weight of cores and mm per number diameter in mm index kg/km kg/km conductor LFLEX CLASSIC 110 1119752 2 X 0,5 4,8 9.6 35 1119003 3 G 0,5 5,1 14.4 42 1119753 3 X 0,5 5,1 14.4 42 1119004 4 G 0,5 5,7 19.2 54 1119754 4 X 0,5 5,7 19.2 54 1119005 5 G 0,5 6,2 24.0 63 1119755 5 X 0,5 6,2 24.0 63 1119007 7 G 0,5 6,7 33.6 81 1119757 7 X 0,5 6,7 33.6 81 1119010 10 G 0,5 8,6 48.0 116 1119012 12 G 0,5 8,9 58.0 131 1119014 14 G 0,5 9,5 67.0 153 1119018 18 G 0,5 10,5 86.4 188 1119021 21 G 0,5 11,7 101.0 221
