X-On Electronics has gained recognition as a prominent supplier of ND30IOT 2121MSM0 across the USA, India, Europe, Australia, and various other global locations. ND30IOT 2121MSM0 are a product manufactured by LUMEL. We provide cost-effective solutions for ND30IOT 2121MSM0, ensuring timely deliveries around the world.

ND30IOT 2121MSM0 LUMEL

Name: ND30IOT 2121MSM0
Brand: LUMEL
SKU: ND30IOT2121MSM0_LUMEL
Availability: InStock
Rating: 5 (11 reviews)

ND30IOT 2121MSM0 electronic component of LUMEL

Images are for reference only
See Product Specifications

Part No.	ND30IOT 2121MSM0
Manufacturer:	LUMEL
Category:	Unclassified
Description:	Meter: network parameters; digital,mounting; LCD TFT 3,5; 1A,5A
Datasheet:
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 809.9464 ea
Line Total: USD 809.95

Availability - 1
Ship by Wed. 27 Nov to Fri. 29 Nov

MOQ: 1 Multiples: 1
Pack Size: 1

ND30IOT 2121MSM0 More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

1

Ship by Wed. 27 Nov to Fri. 29 Nov

MOQ : 1
Multiples : 1

1 : USD 809.9464
6 : USD 778.7966

Specifications

Manufacturer
LUMEL LUMEL

Product Category
Unclassified Unclassified

Mounting
on panel, for DIN rail mounting (optional) on panel, for DIN rail mounting (optional)

Output
relay x2 relay x2

Operating Temperature
- 10 To 55°C - 10 To 55°C

Kind Of Display Used
LCD TFT 3,5 LCD TFT 3,5

Ip Rating
IP65 IP65

Supply Voltage
85 To 253 VAC , 90 To 300 VDC 85 To 253 VAC , 90 To 300 VDC

Kind Of Network
single - phase, three - phase, 3 - wire, 4 - wire single - phase, three - phase, 3 - wire, 4 - wire

Interface
RS485, Ethernet RS485, Ethernet

Input Current
5 A , 1 A 5 A , 1 A

Input Voltage
57.7 To 230 V 57.7 To 230 V

Display Resolution
320x240 320x240

Operating Frequency
45 To 65Hz 45 To 65Hz

Related Items
ATS - 100 ATS - 100

Type Of Meter
network parameters network parameters

Manufacturer Series
ND30IOT ND30IOT

Measurement
AC voltage, frequency, reactive power, active power, apparent power, power factor, AC current, energy, harmonics, THD AC voltage, frequency, reactive power, active power, apparent power, power factor, AC current, energy, harmonics, THD

Kind Of Meter
digital, mounting digital, mounting

Dimensions W X H X D
96x96x77mm 96x96x77mm

Kind Of Measurement
indirect with 1A current transformer, indirect with 5A current transformer indirect with 1A current transformer, indirect with 5A current transformer

Notes:- Show Stocked Products With Similar Attributes.

ND30IOT 2121MSM0 Alternative Parts

We are delighted to provide the ND30IOT 2121MSM0 from our LUMEL manufacturer, at competitive rates not only in the United States, Australia, and India, but also across Europe and beyond. A long established and extensive electronic component distribution network has enhanced our global reach and dependability, ensuring cost savings through prompt deliveries worldwide. Client satisfaction is at the heart of our business, where every component counts and every customer matters. Our technical service team is ready to assist you. From product selection to after-sales support, we strive to deliver a seamless and satisfying experience. Are you ready to experience the best in electronic component distribution? Contact X-ON Electronics today and discover why X-On are a preferred choice for the ND30IOT 2121MSM0 and other electronic components in the LUMEL manufacturer and beyond.
