SF33.0014 Martin SMT

PCB SUPPORT SYSTEM PCB-Support Series 40.5mm PCB-Support Series 55.5mm Flex Support Magnet Holder Securing PCBs in place during hand soldering sometimes becomes a tricky task. PCB edge-connectors or dense population of components can make clamping and supporting PCBs difficult, especially if PCB are asymmetrical or non-rectangular. MARTIN PCB support tools use magnets and are flexible to move on a steel plate to secure a PCB at its optimum location. The PCB supports are designed to clamp the PCB typically over a bottom heater. PCB Holders are top- justified and spring loaded for repeatable positioning. This simple method has proven to be reliable over many years. To accommodate different size bottom heaters, two PCB support heights are available: One with a free clearance of 55,5mm and one with 40,5mm. For large size PCBs, MARTIN offers bottom side supports which can be installed underneath the PCB. Providing bottom side support, sometimes necessary for some applications to prevent deflection and to maintain co-planar surfaces. MARTIN GmbH Fon: +49 (0)8153 9329-30 We refer to our delivery conditions PCB SUPPORT e Argelsrieder Feld 1b Fax.: +49 (0)8153 9329-39 Subject to change without notice V 2013 07 31.docx 82234 Wessling / Germany Web: www.martin-smt.de TECH INFO PCB SUPPORT SYSTEM PCB Support Tools 40.5mm Series HF00.0018 Handy Fix 03/06 base plate only 1 piece 280*380mm HF00.0018 SF30.0004 PCB Support 40.5mm IRF 06 / 07 1.5 mm 1 piece 1.5mm thickness SF30.0004 SF30.0005 PCB Support 40.5mm IRF 3.0 mm 06 / 07 1 piece 3mm thickness SF30.0005 SF03.0004 PCB Magnet Holder 40.5mm 1 piece for IR/IRD/IRH/IRF/HIF and DL/RD x SF03.0014 PCB Magnet Holder Easy Lock 40.5mm (snap) 1 piece for IR/IRD/IRH/IRF/HIF and DL/RD SF03.0010 PCB Support Rail 40.5mm 1 piece for IR/IRD/IRH/IRF/HIF and DL/RD SF33.0010 PCB Magnet Holder Rail 40.5mm 1 piece for IR/IRD/IRH/IRF/HIF and DL/RD SF01.0100 PCB Clip 1 piece For Use With SF03.0010 and SF33.0014 x SF03.0019 PCB Clamping Holder 40.5mm with 3 fingers 1 piece for IR/IRD/IRH/IRF/HIF and DL/RD SF03.0019 SF03.0019 SF36.1005 PCB Flex Support 40.5mm 1 piece 18 pi l=760 SF36.1002 PCB Flex Support 40.5mm 1 piece 12 pi l=520 SF36.1001 PCB Flex Support 40.5mm 1 piece 10 pin l=440mm SF36.1003 PCB Fix Support 40.5mm 1 piece 4 pi 350mm SF36.1004 PCB Fix Support 40.5mm 1 piece 6 pi 515mm SF36.1007 PCB Fix Support 40.5mm 1 piece 9 pi 760mm MARTIN GmbH Fon: +49 (0)8153 9329-30 We refer to our delivery conditions PCB SUPPORT e Argelsrieder Feld 1b Fax.: +49 (0)8153 9329-39 Subject to change without notice V 2013 07 31.docx 82234 Wessling / Germany Web: www.martin-smt.de 3 1.5 36.5 38.0
