1005-572 Megger

Name: 1005-572
Brand: Megger
SKU: 1005572_Megger
Availability: InStock
Rating: 5 (11 reviews)

Images are for reference only
See Product Specifications

Part No.	1005-572
Manufacturer:	Megger
Category:	Clamp Multimeters & Accessories
Description:	AC/DC digital clamp meter; Øcable: 51mm; LCD 3,75 digit (3999)
Datasheet:	1005-572 Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 442.4112 ea
Line Total: USD 442.41

Availability - 1
Ship by Tue. 26 Nov to Thu. 28 Nov

MOQ: 1 Multiples: 1
Pack Size: 1

1005-572 More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

1

Ship by Tue. 26 Nov to Thu. 28 Nov

MOQ : 1
Multiples : 1

1 : USD 442.4112

Specifications

Manufacturer
Megger Megger

Product Category
Clamp Multimeters & Accessories Clamp Multimeters & Accessories

Category
Clamp Multimeters Accessories Clamp Multimeters Accessories

Standard Equipment
test leads, user\\\\s manual, bag test leads, user\\\\s manual, bag

Measuring Instrument Features
automatic power - off, HOLD function (for holding display readout), MIN/MAX function, PEAK function, REL function automatic power - off, HOLD function (for holding display readout), MIN/MAX function, PEAK function, REL function

Kind Of Display Used
LCD 3,75 digit (3999) LCD 3,75 digit (3999)

Conform To The Norm
EN61010 600V CAT IV EN61010 600V CAT IV

Ac Voltage Measuring Accuracy
(1 % + 5 digits) (1 % + 5 digits)

Ac Current Measuring Accuracy
(1 , 5 % + 5 digits) (1 , 5 % + 5 digits)

Dc Current Measuring Accuracy
(1 % + 3 digits) (1 % + 3 digits)

Resistance Measuring Accuracy
± (1 % + 3 digits) ± (1 % + 3 digits)

Frequency Measuring Accuracy
± (1 % + 2 digits) ± (1 % + 2 digits)

Dc Voltage Measuring Accuracy
(0 , 7 % + 2 digits) (0 , 7 % + 2 digits)

Max. Diameter Of Measured Cable
51 mm 51 mm

True Effective Value Measurement
True RMS True RMS

Type Of Meter
AC/DC digital clamp meter AC/DC digital clamp meter

Continuity Test
acoustic indication, <30Ω acoustic indication, <30Ω

Measurement
AC voltage, DC voltage, frequency, DC current, resistance, AC current, continuity AC voltage, DC voltage, frequency, DC current, resistance, AC current, continuity

Bandwidth For Ac Voltage Measurements
50 To 500Hz 50 To 500Hz

Ac Current Measuring Range
400 A , 1 kA , 1.5 kA 400 A , 1 kA , 1.5 kA

Resistance Measuring Range
0 To 400 Ohms 0 To 400 Ohms

Dc Current Measuring Range
400 A , 1 kA , 1.5 kA 400 A , 1 kA , 1.5 kA

Dc Voltage Measuring Range
400 V , 1 kV 400 V , 1 kV

Ac Voltage Measuring Range
400 V , 750 V 400 V , 750 V

Frequency Measuring Range
20...400Hz 20...400Hz

Dimensions
105x275x48mm 105x275x48mm

Bandwidth For Ac Current Measurements
50 To 200Hz 50 To 200Hz

Weight With Battery
524 g 524 g

Power Supply
b A ttery 6LR61 9 V x1 b A ttery 6LR61 9 V x1

Battery/ Rechargeable Battery
battery 6LR61 9V x1 battery 6LR61 9V x1
