SFP-DRH15 Metcal

EAP Cat v2 2013 Oct17 Layout 1 30/10/2013 16:56 Page 2 Hand Soldering, Desoldering & P S - 9 0 0 M F R - 1 1 0 0 M F R - 2 2 0 0 Single Port Dual Port Switchable PS-900 MFR-1100 Series MFR-1300 Series NEW MX-500 Series M U L T I F U N C T I O N NEW STYLE PS-900 Tip Hand-Piece MFR Hand-pieces MX Hand-pieces SmartHeat Technology OK International is the original supplier of SmartHeat Soldering Technology. SmartHeat senses the exact thermal requirement for each solder joint and responds by delivering the precise amount of thermal energy required to create a reliable connection. The result is a high degree of control without resorting to higher tip idle temperatures required by conventional heater process technologies. Consequently, the risk of component and board damage is minimized. This is especially important with the greater thermal demands required by lead-free applications. 2EAP Cat v2 2013 Oct17 Layout 1 30/10/2013 16:56 Page 3 Rework Systems Overview P S - 9 0 0 M F R - 1 1 0 0 M F R - 2 2 0 0 M F R - 1 3 0 0 Single Port Dual Port Switchable Dual Port Simultaneous PS-900 MFR-1100 Series MFR-1300 Series NEW MX-500 Series MFR-2200 Series MX-5200 Series M U L T I F U N C T I O N R E W O R K S Y S T E M S Also compatible with the New MX-500 System NEW STYLE PS-900 Tip Hand-Piece MFR Hand-pieces MX Hand-pieces MFR Hand-pieces MX Hand-pieces SmartHeat Soldering Technology = Variable Power / Fixed Temperature w SmartHeat tips and cartridges sense the load Self-regulating and instantly deliver the right amount of heat Tip Cartridge Ergonomic directly to the solder joint. (see below) Hand-piece w The required solder joint temperature drives the heating process, as opposed to the idle tip temperature setting (as in a conventional iron). Connector Coil w Operates at lower and safer temperatures. Tip Power is delivered in proportion to the load. SmartHeat technology eliminates overshoot. Heater w No calibration required - saves money and eliminates system down-time. Watch our SmartHeat Video on YouTube or www.metcal.com 3
