MC22008B6W-SPTLY-V2 Midas

Electra House, 32 Southtown Road Telephone +44 (0)1493 602602 Great Yarmouth, Norfolk Fax +44 (0)1493 665111 NR31 0DU, England Email:sales midasdisplays.com www.midasdisplays.com M C22008B6W-SPTLY-V2 2 x 20 8mm Character Height LCD Module Specification Version: 1 Date: 2 8 /10/2016 Revision Display Features Operating Temp. Range -20C ~ +70C Viewing Direction 6 OClock STN Yellow/Green Transflective Backlight LED Yellow/Green Controller SPLC780D Characters 2 x 20 Box Quantity Weight / Display Voltage 5V 15 pcs 100 grams Module Size 146.00 x 43.00 x 14.20 mm Character Height 8mm Display Construction Chip on Board * - For full design functionality, please use this specification in conjunction with the SPLC780D specification. (Provided Separately) Optional Variants Display Accessories Physical Fonts Voltage Part Number Description Aspects LCD interconnect board, can be driven from either a MCCMDB-16SIL PC or a single board computer with a USB output. English/Japanese N/A N/A 16 Way, Single in-line to MCCBL1A16SILP Dual In-line connector -16DILS-150 Cable. 16 Way, Single in-line to MCCBL1A16SILP Single In-line connector -16SILS-150 Cable. Mechanical Specifications Module Size 146.00 x 43.00 x 14.20 ( With Backlight) W x H x D mm Viewing Area 123.00 x 23.00 W x H mm Hole-to-Hole 139.00 x 36.00 W x H mm Character Size 4.84 x 9.22 W x H mm Character Pitch 1.16 x 0.53 W x H mm Dot Size 0.92 x 1.10 W x H mm Dot Pitch 0.06 x 0.06 W x H mm MC22008B6W-SPTLY-V2 2 x 20 8mm Character Height LCD Module Specification Version: 1 Date: 2 8/10/2016 Revision
