MCOB22005A1V-EBP Midas

Electra House, 32 Southtown Road Telephone +44 (0)1493 602602 Great Yarmouth, Norfolk Fax +44 (0)1493 665111 NR31 0DU, England Email:sales midasdisplays.com www.midasdisplays.com M COB22005A1V-EBP 2 x 20 Euro /Jap/Cyrillic OLED Module Specification Version: 1 Date: 16/05/2017 Revision Display Features Character Count 2 x 20 Appearance Blue on Black Logic Voltage 5V Interface Parallel Font Set English / European / Cyrillic Character Height 5.55 mm Module Size 116.00 x 37.00 x 9.80 mm Operating Temperature -40C ~ +80C Box Quantity Weight / Display Construction COB --- --- Display Accessories Optional Variants Part Number Description Appearance Voltage LCD Interconnect board, can be Green on Black driven from either a PC or a MCCMDB-16D IL White on Black single Board computer with a Yellow on Black USB output. Red on Black MCCBL1A16D ILP 16 Way, Dual in-line to Dual -DILS-150 in-line connector cable. Mechanical Specifications Module Size 116.00 x 37.00 x 9.80 ( With Backlight) W x H x D mm 85.00 x 18.60 Viewing Area W x H mm Hole-to-Hole 75.00 x 31.00 W x H mm Character Size 3.20 x 5.55 W x H mm Character Pitch 3.90 x 6.25 W x H mm Dot Size 0.60 x 0.65 W x H mm Dot Pitch 0.65 x .70 W x H mm 3.20 0.70 0.65 0.60 DOT SIZE SCALE 5/1 2.5 9.8 MAX 2.54 4.9 16 15 2 1 1.6 PIN DETAIL M CO B 22005A1V - EB P 2 x 20 Euro/Jap/Cyrillic O L E D Module Specification Version: 1 Date: 1 6 / 0 5 / 2 0 1 7 Revision (P2.54*7) 0.75 5.55 17.78 8.34 0.70 0.65 116.0 0.5 13.40 91.2 85.00(VA) 16.50 77.30(AA) 20.03 16 15 1 2 59.0 4.0 108.0 37.0 0.5 25.20 5.90 18.60(VA) 9.20 11.85(AA) 12.58 29.0 4.0
