Product Information

2408NL-05W-B30-P00

2408NL-05W-B30-P00 electronic component of MinebeaMitsumi

Datasheet
DC Fan Axial Ball Bearing 24V 15V to 27.6V 14.83CFM 27dB 60 X 60 X 20mm
Manufacturer: MinebeaMitsumi
Large
This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges



Price (USD)
N/A

Obsolete

 More Buying Options & Price Grid(s)

Availability Price Quantity
0 - WHS 1

MOQ : 1
Multiples : 1

Stock Image

2408NL-05W-B30-P00
MinebeaMitsumi

1 : USD 10.1336
10 : USD 9.5337
N/A

Obsolete
0 - WHS 2

MOQ : 1
Multiples : 1

Stock Image

2408NL-05W-B30-P00
MinebeaMitsumi

1 : USD 10.685
10 : USD 9.7767
25 : USD 9.157
50 : USD 8.7296
N/A

Obsolete

Read More Specifications


Manufacturer
Product Category
RoHS - XON
Icon ROHS
Product
Type
Height
Width
Operating Supply Voltage
Airflow
Speed
Bearing Type
Noise
Power Rating
Frame Dimensions - mm
Housing Material
Termination Style
Series
Length
Pressure Type
Size
Brand
Current Type
Factory Pack Quantity :
Cnhts
Hts Code
Product Type
Subcategory
Taric
Tradename
LoadingGif

Notes:- Show Stocked Products With Similar Attributes.

More Products By Manufacturer "Minebeamitsumi"

Image Description
2408NL-05W-B40-L00 electronic component of MinebeaMitsumi 2408NL-05W-B40-L00

DC Fan Axial Ball Bearing 24V 15V to 27.6V 15.89CFM 29dB 60 X 60 X 20mm
Stock : 119

2410ML-04W-B30-E00 electronic component of MinebeaMitsumi 2410ML-04W-B30-E00

DC Fan Axial Ball Bearing 12V 6V to 13.8V 32.4CFM 31dB 60 X 60 X 25mm Long Life
Stock : 0

2410ML-04W-B49-B00 electronic component of MinebeaMitsumi 2410ML-04W-B49-B00

DC Fan Axial Ball Bearing 12V 21.5CFM 33.5dB 60 X 60 X 25mm
Stock : 177

2410ML-04W-B10-B00 electronic component of MinebeaMitsumi 2410ML-04W-B10-B00

DC Fan Axial Ball Bearing 12V 13.7CFM 23dB 60 X 60 X 25mm
Stock : 180

2408NL-05W-B40-P00 electronic component of MinebeaMitsumi 2408NL-05W-B40-P00

DC Fan Axial Ball Bearing 24V 15V to 27.6V 15.89CFM 29dB 60 X 60 X 20mm
Stock : 0

2410ML-04W-B40-E00 electronic component of MinebeaMitsumi 2410ML-04W-B40-E00

DC Fan Axial Ball Bearing 12V 6V to 13.8V 0.01CFM 33.5dB 60 X 60 X 25mm
Stock : 168

2410ML-04W-B20-B00 electronic component of MinebeaMitsumi 2410ML-04W-B20-B00

DC Fans DC Axial Fan, 60x25mm, 12VDC, 16.9CFM, Rib, 2-Wire
Stock : 1

2410ML-04W-B40-B00 electronic component of MinebeaMitsumi 2410ML-04W-B40-B00

DC Fan Axial Ball Bearing 12V 6V to 13.8V 21.5CFM 33.5dB 60 X 60 X 25mm
Stock : 0

2408NL-05W-B59-L00 electronic component of MinebeaMitsumi 2408NL-05W-B59-L00

DC Fan Axial Ball Bearing 24V 17.6CFM 31.5dB 60 X 60 X 20mm
Stock : 0

2410ML-04W-B30-B00 electronic component of MinebeaMitsumi 2410ML-04W-B30-B00

DC Fan Axial Ball Bearing 12V 6V to 13.8V 19.1CFM 31dB 60 X 60 X 25mm
Stock : 0

More Products By Category "DC Fans"

Image Description
2410ML-04W-B49-B00 electronic component of MinebeaMitsumi 2410ML-04W-B49-B00

DC Fan Axial Ball Bearing 12V 21.5CFM 33.5dB 60 X 60 X 25mm
Stock : 177

3108NL-04W-B59-L00 electronic component of MinebeaMitsumi 3108NL-04W-B59-L00

DC Fan Axial Ball Bearing 12V 44CFM 42dB 80 X 80 X 20mm
Stock : 0

4710KL-04W-B59-E00 electronic component of MinebeaMitsumi 4710KL-04W-B59-E00

DC Fan Axial Ball Bearing 12V 114.7CFM 41.5dB 119 X 119 X 25mm
Stock : 0

4715KL-07W-B39-E00 electronic component of MinebeaMitsumi 4715KL-07W-B39-E00

DC Fan Axial Ball Bearing 48V 108CFM 42.5dB 119 X 119 X 38mm
Stock : 0

1608KL-05W-B59-L00 electronic component of MinebeaMitsumi 1608KL-05W-B59-L00

DC Fan Axial Ball Bearing 24V 9.5CFM 33dB 40 X 40 X 20mm
Stock : 0

4710KL-05W-B59-E00 electronic component of MinebeaMitsumi 4710KL-05W-B59-E00

DC Fan Axial Ball Bearing 24V 114.7CFM 41.5dB 119 X 119 X 25mm
Stock : 0

3110SB-05W-B20-B00 electronic component of MinebeaMitsumi 3110SB-05W-B20-B00

DC Fan Axial Ball Bearing 24V 12V to 27.6V 26.1CFM 19dB 80 X 80 X 25mm
Stock : 0

1N5811US electronic component of EIC Semiconductor 1N5811US

Diode Switching 150V 6A 2-Pin SMB
Stock : 0

1N5408G electronic component of EIC Semiconductor 1N5408G

GLASS PASSIVATED JUNCTION SILICON RECTIFIERS 2DO-201AD
Stock : 182

Additional Infomation About Product

2408NL-05W-B30-P00 Detailed Speci cations 60 mm Frame Width: 60 mm Frame Height: 20 mm Frame Depth: 14.8 CFM Max. Air Flow: 0.42 m3 per min Max. Air Flow: 0.11 In H2O Max. Static Pressure: 28.7 Pa Max. Static Pressure: 3600 RPM Fan Speed: 27 dB Noise: 60 degree C 40,000 Hours AA/EA L10 Life Expectancy: Ball Bearing Bearing Type: 24 V Nominal Voltage: 15 V Operating Voltage - Lower: 27.6 V Operating Voltage - Upper: 0.045 A Current: 1.1 W Input Power: 85 g Mass: No Tach / Locked Rotor Output: EOL Status: NMB Technologies Corporation - A MinebeaMitsumi Group Company - 39830 Grand River Avenue - Novi, MI 48375 info nmbtc.com DC Axial FansX-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for DC Fans category: Click to view products by MinebeaMitsumi manufacturer: Other Similar products are found below : 614R AUB0612L AFB0948HH-S687 G2E085-AA05-10 4318/12T AUB0912H-F00 3412N/2ME W2G110-AM39-01 8412GLV 8412NGL- 12 6448-384 4114N/17-251 4318/2R 4412F/2D 424JMU 4414/2HH 4112 N/12GL-175 9GA0912F402 9GA0812B20011 AFB0824SHBAV1 DV5214/2NP-230 9GA0912H4021 THC1548MGDJJ 9GA0812B2001 GFB1224SHG 8500NU 9WG1212E101-E 3241.124 DC0401012V2B-3T0 ASFP14391 ASFP64371 ASFP64391 ASFP84391 ASFP92391 9A0612G402 AD5012HB-C71 AD5012MB-C71 ASFP84372 ASFP64372 31100-000440-RS 026758A 514F MEC0381V1-000U-G99 4292 MF60152V1-1000U-G99 3610KL-04W-B50-D00 109P0412K3023 EE92251B1-000U-F99 8218J/2H4P PF60381B1-000U-S99
