500-706-11 Mitutoyo

Small Tool Instruments and Data Management INDEX Caliper SuperCaliper 126 ABSOLUTE Solar Caliper 127 Digimatic Caliper ABSOLUTE Coolant Proof Caliper 128 ABSOLUTE Digimatic Caliper 130 Vernier Caliper 132 ABSOLUTE Digimatic & Vernier Caliper 138 Dial Caliper 140 Digimatic Carbon Fiber Caliper 141 Digimatic Vernier Caliper (Nib Style Jaws) 144 Long Jaw Vernier Caliper 145 Height Gages Offset Caliper 146 Offset Centerline Caliper 147 ABSOLUTE Back-Jaw Centerline Caliper 148 Point Caliper 149 Blade Type Caliper 150 Linear Height Neck Caliper 151 ABSOLUTE Inside Caliper 152 Tube Thickness Caliper 154 Hook Type Vernier Caliper 155 Swivel Vernier Caliper 155 ABSOLUTE Low Force Caliper 156 ABSOLUTE Snap Caliper 156 Depth Gages Scribing Caliper 157 MyCAL-Lite 158 Plastic Caliper 158 Height Gages Heightmatic 159 Digimatic Height Gage 160 ABSOLUTE Digimatic Height Gage 162 Dial Height Gage 164 Vernier Height Gage 166 New Products CERA Caliper Checker 168 Carbide-tipped Scriber 169 Optional Accessories 169 Linear Height Linear Height 170 SuperCaliper QM-Height 172 Depth Gages Depth Micrometer 174 Depth Gage 175 Depth Micro Checker 175 ABSOLUTE Digimatic Depth Gage 176 ABSOLUTE Vernier Depth Gage 177 Coolant Proof Caliper Dial Depth Gage 178 Extension Bases 179 Depth Base Attachment 179 ABSOLUTE Digimatic/Dial Depth Gage 180 ABSOLUTE Tire Thread Depth Gage 182 Digimatic Caliper ABSOLUTE Digimatic Offset Caliper ABSOLUTE Digital Height Gage 125SuperCaliper SERIES 500 No battery or origin reset needed for IP67 digital caliper FEATURES Worlds unique* solar-powered With no annoying origin restoration SuperCaliper that is eco-friendly with no necessary, a measurement can be started battery any time and there is no restriction on *According to Mitutoyo research in January, 2005 operating speed. The impact resistance of the display unit has been increased for improved usability (Refer to the page 9 for details.) in workshop conditions. IP67 protection assures waterproof reliability. This SuperCaliper uses components that do not contain harmful substances and is compatible with RoHS Directives. (Refer to the page 9 for details.) Improvement in surface nish of beam Conventional SuperCaliper Technical Data Accuracy: 0.02mm (excluding quantizing error) Resolution: 0.01mm or .0005 /0.01mm Direction of the length Direction of the length Repeatability: 0.01mm Display: LCD Ra: 0.126m Ra: 0.07m Length standard: ABSOLUTE electromagnetic induction linear encoder Max. response speed: Unlimited Battery: Solar battery* Dust/Water protection level: IP67 *Can be used continuously above 60lux ambient illumination. Function Origin-set, inch/mm conversion (inch/mm models) Alarm: Counting value composition error 500-774 Optional Accessory 05CZA624: SPC cable with data switch (1m) 05CZA625: SPC cable with data switch (2m) IP67 protection level Level 6: Dust-tight No ingress of dust. Level 7: Protected against the effects of temporary SPECIFICATIONS immersion in water. Ingress of water in quantities causing harmful Metric Inch/Metric effects shall not be possible when the enclosure Range Order No. Remarks Range Order No. Remarks is temporarily immersed 1 meter in water under standardized conditions of pressure and time (30 0 - 150mm 500-776 with data output 0 - 6 500-786 with data output min.). 0 - 150mm 500-774 w/o data output 0 - 6 500-784 w/o data output 0 - 200mm 500-777 with data output 0 - 8 500-787 with data output 0 - 200mm 500-775 w/o data output 0 - 8 500-785 w/o data output DIMENSION Unit: mm About the charge function (SuperCaliper) The minimum illumination required in the uncharged state is 60lux. As shown in the table JIS Z 9110 Articial Illumination Intensity Standard, this SuperCaliper can be used without problems in a normal work environment. The charge function allows the operator to use this SuperCaliper without interrupting work even if the ambient illumination is temporarily insufcient. Range L a b c d In the fully charged state this SuperCaliper can operate 0 - 150mm 233 21 16.5 40 16 for approximately an hour in an environment of 50lux illumination (less than the minimum necessary illumination 0 - 200mm 290 24.5 20 50 16 intensity). Jaw thickness: 3.5mm The time necessary for full charge differs, depending on the charging conditions. If this SuperCaliper is left unused in an illumination of 500 lux (usual for manufacturing environments), it takes approximately one hour to reach full charge. 126
