PRODUCT SPECIFICATION Certificato N. 9125.FLA2 ISO 9001 CABLE SERIES 155321 Servo Motor - UL AWM recognized - WSOR jacket (Weld-Slag and Oil-Resistant ) Style 21939 (80C / 1000V) 1. CONSTRUCTION DATA 1.1 CONDUCTOR: Bare copper strand according to EN 13602 - ETP1 stranding according to DIN VDE 0295, EN60228 Class 6 Stranded lay compliant with UL 758. 1.2 WIRE STRUCTURE: Signal Diameter of Stranding Max Resistance Nominal Section AWG (nbr of wires x wire Ref. std. IEC 60344 stranded core (mm) diameter in mm) ( /km) (mm) 0.75 19 42x0.15 1.20 27.7 1.00 18 52x0.15 1.32 22.4 1.50 16 81x0.15 1.50 14.4 Power Diameter of Stranding Max Resistance Nominal Section AWG (nbr of wires x wire Ref. std. IEC 60344 stranded core (mm) diameter in mm) ( /km) (mm) 1.50 16 81x0.15 1.50 14.4 2.50 14 133x0.15 2.10 8.7 4.00 12 78x0.254 2.60 5.2 6.00 10 117x0.254 3.15 3.5 1.3 INSULATION: Thermoplastic Elastomer compound Max Insulation resistance >600 Gxkm (IEC60189-1&IEC60885-1 or EN50289-1-4) nominal hardness 50 Shore D according to UL758 1.4 INSULATION DIAMETER Signal Nominal section Nominal Nominal thickness (mm) (mm) (mm) 0.75 1.80 0.30 1.00 2.00 0.34 1.50 2.15 0.32 Power Nominal section Nominal Nominal thickness (mm) (mm) (mm) 1.50 2.35 0.42 2.50 3.00 0.45 4.00 3.60 0.50 6.00 4.50 0.68 REVISION HISTORY ECR/ECN INFORMATION: TITLE: Page Rev.A1 26/02/2016 RELEASED SERVO MOTOR WSOR jacket 1 of 4 Document Number: Created/Revised by: Checked by: Approved by: 1553210001 PS P1E A1 M. Arrigoni A. Defendi C. Lerose THIS DOCUMENT CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION Template: TDS REV.0 22/07/2015 PRODUCT SPECIFICATION Certificato N. 9125.FLA2 ISO 9001 1.5 ASSEMBLY: 1.5.1 Signal Pair Cores stranded in pairs (one or two). Each pair is shielded with Tin copper wire (Braid type - nominal optical coverage 85%) and wrapped with tape 1.5.2 Total Assembly Power Cores and Signal Pair (if present) stranded together, fillers may be used for a better roundness. 1.6 TAPE: Wrap over assembly 1.7 BRAID SHIELD: Tin copper wire, nominal optical coverage 85%. 1.8 TAPE: Wrap over shield 1.9 JACKET: Special compound Polyurethane based, nominal hardness 78 Shore A Silicone, Pb,Cd,Hg & FCKW free according to UL758. For overall diameter, jacket and cores colors refer to Annex 1 2. TECHNICAL DATA 2.1 ELECTRICAL: Voltage rating 1000 Vrms (for electronic use) Voltage test on core (Power) 3000 Vrms x 1 min. (IEC60885-1) Voltage test on core (Brake) 3000 Vrms x 1 min. (IEC60885-1) 2.2 TEMPERATURE: Temperature range (fixed) -40 C to +90C (3000h ISO6722 pending) Temperature range (flex) -25C to +80C (free motion without periodic recurrence and forced guidance) Temperature range (drag chain) -5C to +60C 2.3 CHEMICAL: Oil resistance UL758/UL2556 (4 days 100C - IRM902 oil) Free of FCKW, Silicone and Pb yes Halogen free no 2.4 PHYSICAL: UV resistant yes (UL1581/2556 300h) Max installation pulling force 100N Bending radius (fixed) >5xOD Bending radius (flex) >10xOD Bending radius (drag chain) >12xOD (up to 5Mio 20C in freely suspended chain)* Torsion 20C optimal recommended 30/m * *Default criterium of the norm-bendings is electrical failure due to conductor breakage or conductor short-circuit. Extreme sheath adhesion is not a default criterium since it cannot be influenced by the cable manufacturer (e.g. through big abrasion between cable and chain, non-suitable chain construction or wrong installation of cable in the chain). REVISION HISTORY ECR/ECN INFORMATION: TITLE: Page Rev.A1 26/02/2016 RELEASED SERVO MOTOR WSOR jacket 2 of 4 Document Number: Created/Revised by: Checked by: Approved by: 1553210001 PS P1E A1 M. Arrigoni A. Defendi C. Lerose THIS DOCUMENT CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION Template: TDS REV.0 22/07/2015
