Reference Only Spec No. JELF243C-0024B-01 P.1/12 CHIP COIL (CHIP INDUCTORS) LQP03TQ02D Reference Specification 1.Scope This reference specification applies to LQP03TQ series, Chip coil (Chip Inductors). 2.Part Numbering (ex) LQ P 03 T Q 0N6 W 0 2 D Product ID Structure Dimension Applications Category Inductance Tolerance Features Electrode Packaging (LW) and D:Taping Characteristics *B:Bulk *Bulk packing also available. (A product is put in the plastic bag under the taping conditions.) 3.Rating Operating Temperature. 55C to +125C Storage Temperature. 55C to +125C Self Resonant DC Rated Customer MURATA Frequency Inductance Q Resistance Current (MHz) Part Number Part Number (min) ( max) (mA) (nH) Tolerance Min. *Typ. LQP03TQ0N6W02D LQP03TQ0N6B02D 0.6 LQP03TQ0N6C02D 20000 LQP03TQ0N7W02D LQP03TQ0N7B02D 0.7 0.05 1000 LQP03TQ0N7C02D LQP03TQ0N8W02D LQP03TQ0N8B02D 0.8 LQP03TQ0N8C02D 18000 LQP03TQ0N9W02D LQP03TQ0N9B02D 0.9 LQP03TQ0N9C02D LQP03TQ1N0W02D LQP03TQ1N0B02D 1.0 >20000 W:0.05H LQP03TQ1N0C02D B:0.1H 0.08 800 LQP03TQ1N1W02D C:0.2H LQP03TQ1N1B02D 1.1 LQP03TQ1N1C02D 17000 LQP03TQ1N2W02D LQP03TQ1N2B02D 1.2 LQP03TQ1N2C02D LQP03TQ1N3W02D 17 LQP03TQ1N3B02D 1.3 LQP03TQ1N3C02D 700 LQP03TQ1N4W02D LQP03TQ1N4B02D 1.4 16000 LQP03TQ1N4C02D LQP03TQ1N5W02D LQP03TQ1N5B02D 1.5 19700 LQP03TQ1N5C02D 0.10 LQP03TQ1N6B02D 1.6 19000 LQP03TQ1N6C02D 15000 LQP03TQ1N7B02D 1.7 17200 LQP03TQ1N7C02D LQP03TQ1N8B02D 1.8 16900 LQP03TQ1N8C02D 650 LQP03TQ1N9B02D B:0.1H 1.9 16100 LQP03TQ1N9C02D C:0.2H 12500 LQP03TQ2N0B02D 2.0 16300 LQP03TQ2N0C02D LQP03TQ2N1B02D 2.1 14300 LQP03TQ2N1C02D 0.12 11000 LQP03TQ2N2B02D 2.2 13000 LQP03TQ2N2C02D MURATA MFG.CO.,LTD Reference Only Spec No. JELF243C-0024B-01 P.2/12 Self Resonant DC Rated Customer MURATA Frequency Inductance Q Resistance Current (MHz) Part Number Part Number (min) ( max) (mA) (nH) Tolerance Min. *Typ. LQP03TQ2N3B02D 2.3 LQP03TQ2N3C02D 11000 12600 LQP03TQ2N4B02D 2.4 LQP03TQ2N4C02D LQP03TQ2N5B02D 0.15 550 2.5 12300 LQP03TQ2N5C02D LQP03TQ2N6B02D 2.6 12100 LQP03TQ2N6C02D LQP03TQ2N7B02D 2.7 12810000 00 LQP03TQ2N7C02D LQP03TQ2N8B02D 2.8 12300 LQP03TQ2N8C02D LQP03TQ2N9B02D 2.9 1240.20 00 500 LQP03TQ2N9C02D LQP03TQ3N0B02D 3.0 12100 LQP03TQ3N0C02D LQP03TQ3N1B02D 3.1 11800 LQP03TQ3N1C02D 9500 LQP03TQ3N2B02D 3.2 0.24 11400 B:0.1H LQP03TQ3N2C02D C:0.2H LQP03TQ3N3B02D 3.3 11200 450 LQP03TQ3N3C02D LQP03TQ3N4B02D 3.4 LQP03TQ3N4C02D 10100 LQP03TQ3N5B02D 3.5 8000 LQP03TQ3N5C02D LQP03TQ3N6B02D 3.6 9900 LQP03TQ3N6C02D 0.25 LQP03TQ3N7B02D 3.7 9800 LQP03TQ3N7C02D 17 400 LQP03TQ3N8B02D 3.8 9700 LQP03TQ3N8C02D LQP03TQ3N9B02D 3.9 LQP03TQ3N9C02D 10500 LQP03TQ4N0B02D 4.0 LQP03TQ4N0C02D LQP03TQ4N1B02D 4.1 6500 10100 LQP03TQ4N1C02D 360 LQP03TQ4N2B02D 4.2 0.35 10000 LQP03TQ4N2C02D LQP03TQ4N3H02D 4.3 9900 LQP03TQ4N3J02D LQP03TQ4N7H02D 4.7 8800 LQP03TQ4N7J02D LQP03TQ5N1H02D 5.1 8400 350 LQP03TQ5N1J02D 0.39 LQP03TQ5N6H02D 5.6 8800 LQP03TQ5N6J02D 6000 LQP03TQ6N2H02D 6.2 8300 LQP03TQ6N2J02D H:3% LQP03TQ6N8H02D J:5% 0.55 6.8 5400 7900 300 LQP03TQ6N8J02D LQP03TQ7N5H02D 7.5 7600 LQP03TQ7N5J02D 4800 LQP03TQ8N2H02D 8.2 7100 LQP03TQ8N2J02D 0.65 LQP03TQ9N1H02D 9.1 6600 250 LQP03TQ9N1J02D 4500 LQP03TQ10NH02D 10 0.69 6300 LQP03TQ10NJ02D MURATA MFG.CO.,LTD
