EB2-12SNU NEC

Miniature Signal Relays EA2/EB2 Overview Applications The KEMET EA2/EB2 miniature signal relays offer a Electronic switching systems c o m pa c t c as e size i n a fla t pa c ka g e . M i ni mal b oa r d s pa c e PBX is consumed with either a through-hole or surface mount Terminal equipment c o n fi g u r a ti o n . T h es e r e lays a r e r e c o g nize d by U L a n d C S A , Telephone systems while also being compliant with Part 68 of the FCCs 1,500 V surge capacity. Benefits Low power consumption (< 200 mW) Compact and lightweight Low magnetic interference Breakdown voltage: 1,000 VAC (1,500 VAC surge), FCC Part 68 compliant Tube or embossed tape and reel packaging U L r e c o g nize d ( E 7 3 26 6) a n d C S A c e r ti fi e d ( L R 4 626 6) Surface mount and through-hole options Part Number System EB2- 3 S NU -L Series Coil Voltage Latch Type Lead Type Packaging EA2- = Through-hole mount 3 = 3 VDC Blank = Non-latch type NU = Standard Blank = Tube EB2- = Surface mount 4.5 = 4.5 VDC S = Single coil latch type NJ = Trimmed -L = Embossed tape on reel 5 = 5 VDC T = Double coil latch type 12 = 12 VDC 24 = 24 VDC Built Into Tomorrow KEMET Electronics Corporation KEMET Tower One East Broward Boulevard R7001 EA2 EB2 5/19/2021 1 Fort Lauderdale, FL 33301 USA 954-766-2800 www.kemet.comMiniature Signal Relays EA2/EB2 Dimensions Millimeters EA2 Series B Maximum D Maximum H Maximum 0.33 0.5 0.25 K P P 2 1 General tolerance: 0.2 EB2 Series D Maximum B Maximum H Maximum 0.25 0.5 K P 1 P 2 General tolerance: 0.2 11.5 Series D H B P P K 1 2 EA2 (NU) 14.2 5.4 9.2 2.54 7.62 3.5 EA2 (NJ) 14.2 5.4 9.2 2.54 7.62 2.8 EB2 14.3 7.5 9.3 2.54 7.62 1.35 KEMET Electronics Corporation KEMET Tower One East Broward Boulevard R7001 EA2 EB2 5/19/2021 2 Fort Lauderdale, FL 33301 USA 954-766-2800 www.kemet.com
