NPIM74PR47MTRF NIC

NPIM Shielded Power Inductors NPIM P Series FEATURES SHIELDED POWER INDUCTOR RoHS MOLDED METAL COMPOSITE CONSTRUCTION HIGH SATURATION CURRENT (~ 125A) Compliant includes all homogeneous materials HIGH EFFICIENCY (2X IMPROVEMENT OVER FERRITE CORE INDUCTORS) *See Part Number System for Details LOW PROFILES CHARACTERISTICS Case Code NPIM31P NPIM41P NPIM42P NPIM50P NPIM51P Inductance Range ( H) 0.47 ~ 1.0 0.1 ~ 10 0.1 ~ 22 0.1 ~ 10 0.33 ~ 10 Case Code NPIM58P NPIM52P NPIM53P NPIM70P NPIM71P Inductance Range ( H) 0.33 ~ 10 0.33 ~ 10 0.33 ~ 10 0.22 ~ 10 0.22 ~ 10 Case Code NPIM78P NPIM72P NPIM73P NPIM74P NPIM84P Inductance Range ( H) 0.33 ~ 10 0.1 ~ 10 0.33 ~ 10 0.22 ~ 33 0.19 ~ 47 Case Code NPIM104P NPIM147P NPIM187P Inductance Range ( H) 0.22 ~ 33 0.33 ~ 10 0.45 ~ 100 Operating Temperature Range -40C ~ +125C (Ambient + Self-Heating) (-55C ~ +125C for 84 and 147 case sizes) Temperature Rise at Irms +40C Inductance Change at Isat -20% Inductance Tolerance 20% (M), 30% (Y) Resistance to Solder Heat 260C 5C for 10 seconds DIMENSIONS (mm) Series A B C D E F G H NPIM31P 3.5 0.2 3.2 0.2 1.0 0.2 0.7 0.2 1.2 0.2 1.9 4.1 1.45 NPIM41P 4.45 0.25 4.06 0.25 1.0 0.2 0.76 0.30 2.0 0.20 2.2 5.2 2.3 NPIM42P 4.45 0.25 4.06 0.25 1.8 0.2 0.76 0.30 2.0 0.20 2.2 5.2 2.4 NPIM50P 5.7 0.3 5.2 0.2 1.0 0.2 1.1 0.3 2.5 0.3 2.2 6.2 2.8 NPIM51P 5.7 0.3 5.2 0.2 1.3 0.2 1.1 0.3 2.5 0.3 2.2 6.2 2.8 NPIM58P 5.7 0.3 5.2 0.2 1.6 0.2 1.1 0.3 2.5 0.3 2.2 6.2 2.8 NPIM52P 5.7 0.3 5.2 0.2 1.8 0.2 1.1 0.3 2.5 0.3 2.2 6.2 2.8 NPIM53P 5.7 0.3 5.2 0.2 2.8 0.2 1.1 0.3 1.5 0.2 2.5 6.2 1.8 NPIM70P 7.0 0.3 6.6 0.3 1.0 0.2 1.8 0.3 2.5 0.3 2.5 7.7 3.0 NPIM71P 7.0 0.3 6.6 0.3 1.3 0.2 1.8 0.3 3.0 0.3 2.5 7.7 3.5 NPIM78P 7.0 0.3 6.6 0.3 1.6 0.2 1.8 0.3 3.0 0.3 2.5 7.7 3.5 NPIM72P 7.0 0.3 6.6 0.3 1.8 0.2 1.8 0.3 3.0 0.3 2.5 7.7 3.5 NPIM73P 7.0 0.3 6.6 0.3 2.2 0.2 1.8 0.3 3.0 0.3 2.5 7.7 3.5 NPIM74P 7.3 0.3 6.6 0.3 2.8 0.2 1.8 0.3 3.0 0.3 2.5 8.4 3.5 R19 ~ R82 3.0 0.5 NPIM84P 8.6 0.3 8.0 0.3 3.8 0.2 1.8 0.3 4.6 10.6 3.8 1R0 ~ 330 3.2 0.5 NPIM104P 11.0 0.5 10.0 0.3 3.8 0.2 2.3 0.3 3.0 0.3 5.4 13.6 3.5 NPIM147P 13.4 0.5 12.5 0.3 6.8 0.2 2.3 0.3 3.0 0.5 8.0 14.5 5.0 NPIM187P 17.6 0.4 16.9 0.3 6.7 0.3 2.1 0.3 11.9 0.3 12.2 18.5 12.5 A F D C 1R0 H B E G LAND PATTERN NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.com 1 SPECIFICATIONS SUBJECT TO CHANGENPIM Shielded Power Inductors NPIM P Series PART NUMBER SYSTEM REFLOW SOLDERING PROFILE NPIM 73 P R47 M TR F PRE-HEATING NATURAL SOLDERING COOLING RoHS Compliant 20~40s Packaging: TR = Tape & Reel 260C / 40s max. Inductance Tolerance Code: M=20% Inductance Code ( H): 1st two digits are significant, 3rd digit is multiplier. Series Code 217 Size Code (see table for details) Metal Composite Power Inductor 200 60~150s 150 60~180s 480s max. TIME( sec.) REFLOW TIMES: 3X MAX. NPIM31P Size STANDARD VALUES - CASE SIZE Size 31P (3.5 x 3.2 x 1) Part Number Inductance Value Typ. DCR Max. DCR DC Current DC Current Test Frequency ( H) (m ) (m ) Irms (Amps) Isat (Amps) NPIM31PR47MTRF 0.47 20% 25 30 5.0 7.2 100KHz NPIM31P1R0MTRF 1.00 20% 50 60 3.3 5.5 Maximum +40C temperature rise at Irms. Typical -20% inductance change at Isat Contact NIC for NPIM P Performance Curves NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com www.RFpassives.com www.SMTmagnetics.com 2 SPECIFICATIONS SUBJECT TO CHANGE
