S 30 ALUMINUM ELECTROLYTIC CAPACITORS Screw Terminal Type, 105C High Voltage, Smaller Sized. NU series Suited for use in industrial power supplies for inverter circuitry, etc. Rated voltage range up to DC525V. NU Load life of 5000 hours application of ripple current at 105C. High voltage / Smaller sized than NT series. High Coped with loading of high speed charge-discharge. Voltage Smaller Suited for high frequency regenerative voltage for AC servomotor, general inverter. NT Compliant to the RoHS directive (2011/65/EU). Specifications Item Performance Characteristics Category Temperature Range 40 to +105C Rated Voltage Range 400 to 525V 680 to 18000 F Rated Capacitance Range 3 CV Capacitance Tolerance 20% (120Hz, 20C) 3 After 5 minutes application of rated voltage, leakage current is not more than (CV A) or 5 mA, whichever is smaller. (at 20C) Leakage Current C : Rated Capacitance(F), V : Voltage ( V ) 3 CV Tangent of loss angle (tan ) 0.2MAX. (120Hz at 20C) Measurement frequeny : 120Hz Rated voltage(V) 400 to 525 Stability at Low Temperature Z 40C / Z+20C Impedance ratio ZT/Z20(MAX.) 8 Insulation Resistance The insulation resistance shall be more than 100M at DC 500V application between terminal and bracket. Voltage proof There is no abnormality during AC 2500V 1 minute s application between terminal and bracket. The specifications listed at right shall be met when the capacitors are Capacitance change Within 20% of the initial capacitance value restored to 20C after D.C. bias plus rated ripple current is applied for Endurance tan 200% or less than the initial specified value 5000 hours at 105C, the peak voltage shall not exceed the rated Leakage current Less than or equal to the initial specified value voltage. Capacitance change Within 20% of the initial capacitance value After storing the capacitors under no load at 105C for 1000 hours Shelf Life and then performing voltage treatment based on JIS C 5101-4 tan 200% or less than the initial specified value clause 4.1 at 20C, they shall meet the reguirements listed at right. Leakage current Less than or equal to the initial specified value Capacitance change Within 20% of the initial capacitance value After an application of charge-discharge voltage for 50million times Endurance of charge - (charge-discharge voltage difference(V) = rated voltage 0.3, cycle 3Hz) tan 200% or less than the initial specified value discharge behavior capacitors shall meet the characteristics requirement listed at right. Leakage current Less than or equal to the initial specified value Printed with white color letter on black sleeve Marking Drawing Screw terminal types for 51 and larger Type numbering system (Example : 500V 4700 F) Hexagenal headed bolt Bottom plate Sleeve 1 2 3 4 5 6 7 8 9 10 11 12 13 14 Pressure relief vent L N U 2 H 4 7 2 M S E H Mounting bracket ( ) 51 to 90 3-leg brackets Case dia. code Code less BB 2-leg brackets D Code BN No brackets 51 F Configuration Code less Stud mount type 63.5 G Capacitance tolerance (20%) 2 P h 76.2 H Rated Capacitance (4700F) B 2 A 90 J 1 H Rated voltage (500V) + MAX. L 1 Series name U Type S B Configuration 3-leg brackets for 90 capacitors have different standerd stud mount type specifications hole shapes from the ordinary ones illustrated SE TE below. Note) The terminal bolts and mounting brackets will be delivered. Resin bushing available upon request. Please refer to page 328 for schematic of dimensions. P Please contact to us if PVC less products are required. Pressure relief vent 7 Dimensions of mounting bracket (mm) Note) The brackets will be supplied in the separate box. Leg shape 3- -Leg 2- -Leg Dimension of terminal pitch (W) and length (R) and Nominal dia.of bolt (mm) D Symbol 51 63.5 76.2 90 51 63.5 76.2 90 D W R Nominal dia. of bolt P 32.5 38.1 44.5 50.8 33.2 40.5 46.5 53 51 22.0 6 3 A 38.5 43 49.2 58.5 40 46.5 53 59 M 5 63.5 28.6 6 3 M 5 T 7.5 8.0 7.0 8.0 6.0 7.0 6.0 6.0 76.2 31.8 6 3 S 5.0 5.0 5.0 5.0 4.5 4.5 4.5 4.5 M 5 90 31.8 6 3 M 5 U 12 14 14 18 14 14 14 14 60 60 60 60 30 30 30 30 H 20 25 30 35 25 35 35 35 About product of stud bolt h 15 20 24 25 15 20 20 20 Nylon nut and nylon washer attachment become the standard specifications. (cf. P.328) It is not attached to the bracket. Dimension table in next page. Field 13 and 14 become blank in Type number system. CAT.8100D 120 T U 5 1 W +2MAX D T P 2 AALUMINUM ELECTROLYTIC CAPACITORS NU series Dimensions 400V (2G) 450V (2W) Cap. Cap. Size Rated ripple Leakage Current Size Rated ripple Leakage Current tan Code tan Code (F) D L(mm) (mA) (F) D L(mm) (mA) (Arms) (Arms) 2700 63.5 80 11.9 0.20 3.12 LNU2G272MSEG 2700 63.5 100 13.1 0.20 3.31 LNU2W272MSEG 63.5 95 13.6 0.20 3.45 LNU2G332MSEG 63.5 120 15.0 0.20 3.66 LNU2W332MSEG 3300 3300 76.2 75 13.1 0.20 3.45 LNU2G332MSEH 76.2 95 14.4 0.20 3.66 LNU2W332MSEH 63.5 100 14.6 0.20 3.75 LNU2G392MSEG 63.5 135 16.3 0.20 3.97 LNU2W392MSEG 3900 3900 76.2 85 14.3 0.20 3.75 LNU2G392MSEH 76.2 105 15.4 0.20 3.97 LNU2W392MSEH 63.5 120 16.1 0.20 4.11 LNU2G472MSEG 63.5 165 18.5 0.20 4.36 LNU2W472MSEG 4700 4700 76.2 95 15.8 0.20 4.11 LNU2G472MSEH 76.2 130 17.9 0.20 4.36 LNU2W472MSEH 63.5 135 17.7 0.20 4.49 LNU2G562MSEG 76.2 150 20.5 0.20 4.76 LNU2W562MSEH 5600 5600 76.2 105 17.1 0.20 4.49 LNU2G562MSEH 90 105 19.6 0.20 4.76 LNU2W562MSEJ 76.2 125 19.5 0.20 4.95 LNU2G682MSEH 76.2 170 23.4 0.20 5.00 LNU2W682MSEH 6800 6800 90 105 18.8 0.20 4.95 LNU2G682MSEJ 90 125 22.5 0.20 5.00 LNU2W682MSEJ 76.2 170 24.2 0.20 5.00 LNU2G822MSEH 76.2 195 25.7 0.20 5.00 LNU2W822MSEH 8200 8200 90 125 23.1 0.20 5.00 LNU2G822MSEJ 90 145 24.7 0.20 5.00 LNU2W822MSEJ 10000 10000 90 145 25.9 0.20 5.00 LNU2G103MSEJ 90 165 27.3 0.20 5.00 LNU2W103MSEJ 12000 12000 90 165 30.1 0.20 5.00 LNU2G123MSEJ 90 195 29.9 0.20 5.00 LNU2W123MSEJ 15000 90 195 33.5 0.20 5.00 LNU2G153MSEJ 15000 90 235 34.5 0.20 5.00 LNU2W153MSEJ 18000 90 235 38.0 0.20 5.00 LNU2G183MSEJ 500V (2H) 525V (N7) Cap. Cap. Size Rated ripple Leakage Current Size Rated ripple Leakage Current tan Code tan Code D L(mm) D L(mm) (F) (Arms) (mA) (F) (Arms) (mA) 680 51 75 4.0 0.20 1.75 LNU2H681MSEF 680 51 85 4.4 0.20 1.75 LNUN7681MSEF 1000 1000 51 90 5.0 0.20 2.12 LNU2H102MSEF 51 95 5.4 0.20 2.12 LNUN7102MSEF 1500 51 115 5.7 0.20 2.32 LNU2H122MSEF 63.5 95 7.2 0.20 2.60 LNUN7152MSEG 1200 63.5 80 5.7 0.20 2.32 LNU2H122MSEG 1800 63.5 105 8.0 0.20 2.85 LNUN7182MSEG 51 135 6.6 0.20 2.60 LNU2H152MSEF 63.5 135 9.2 0.20 3.15 LNUN7222MSEG 1500 2200 63.5 90 6.6 0.20 2.60 LNU2H152MSEG 76.2 100 9.2 0.20 3.15 LNUN7222MSEH 63.5 100 7.4 0.20 2.85 LNU2H182MSEG 2700 76.2 115 10.6 0.20 3.49 LNUN7272MSEH 1800 3300 76.2 70 7.4 0.20 2.85 LNU2H182MSEH 76.2 140 12.1 0.20 3.85 LNUN7332MSEH 63.5 120 8.5 0.20 3.15 LNU2H222MSEG 76.2 185 15.2 0.20 4.60 LNUN7472MSEH 2200 4700 76.2 95 8.5 0.20 3.15 LNU2H222MSEH 90 135 15.2 0.20 4.60 LNUN7472MSEJ 63.5 135 9.6 0.20 3.49 LNU2H272MSEG 5600 90 155 17.5 0.20 5.00 LNUN7562MSEJ 2700 Rated ripple current (Arms) at 105C 120Hz 76.2 105 9.6 0.20 3.49 LNU2H272MSEH 63.5 165 10.9 0.20 3.85 LNU2H332MSEG 3300 76.2 130 10.9 0.20 3.85 LNU2H332MSEH 76.2 145 12.4 0.20 4.19 LNU2H392MSEH 3900 90 105 12.4 0.20 4.19 LNU2H392MSEJ 76.2 165 13.9 0.20 4.60 LNU2H472MSEH 4700 90 125 13.9 0.20 4.60 LNU2H472MSEJ 5600 90 145 15.8 0.20 5.00 LNU2H562MSEJ 6800 90 165 18.5 0.20 5.00 LNU2H682MSEJ 8200 90 205 20.2 0.20 5.00 LNU2H822MSEJ Frequency coefficient of rated ripple current Frequency (Hz) 50 60 120 360 1k 10k or more Coefficient 0.80 0.82 1.00 1.20 1.30 1.40 CAT.8100D
