BSP Pipe Fittings 1 /8 1 BSP l Suitable for most general industrial purposes l Manufactured from extruded bar or hot brass stampings l Reliable and corrosion resistant Technical Data Thread Sizes 1 1 3 1 3 Medium: /8 , /4 , /8 , /2 , /4 , 1 BSP Compressed air or any hydraulic fluids which are compatible with the materials indicated below. Operating Pressure: Dependent upon the type of tube being used, refer to Section 9.12 for details of tubing Operating Temperature: Dependent upon the type of tube being used, refer to Section 9.12 for details of tubing Materials Brass to BS 2874:1986 (CZ121) for items manufactured from bar, brass to BS 2872: 1969 (CZ122) for items manufactured from stampings. Banjo bolts have a bright nickel plated finish. Ordering Information To order, quote appropriate product number from the tables on the following pages. 9/90 9.8.001.01BSP Pipe Fittings Plug G E D Metric Male taper BSP thread Product B D E G number thread A/F BSP 1 36 0561 01 /8 14,5 10 9,5 1 36 0561 02 /4 16,5 14 11,1 3 36 0561 03 /8 19,0 17 12,7 1 36 0561 04 /2 22,5 22 15,9 Plug E G D Metric Inch Male parallel BSP thread Male parallel BSP thread Product B D E G Product B D E G number thread A/F number thread A/F BSP BSP 1 1 36 0523 01 /8 13 13 7,4 34 0272 01 /8 0,56 0,45 0,31 1 1 36 0523 02 /4 17 19 11,0 34 0272 02 /4 0,56 0,60 0,34 3 3 36 0523 03 /8 19 24 11,4 34 0272 03 /8 0,63 0,82 0,37 1 1 36 0523 04 /2 23 27 15,0 34 0272 04 /2 0,75 0,92 0,44 3 36 0523 06 /4 26 36 16,3 36 0523 08 1 30 41 19,1 Sealing washer should be ordered separately, see page 9.8.001.09 Flanged Plug G D Inch Male parallel BSP thread Product B D E G number thread A/F BSP 1 34 0276 01 /8 0,59 0,45 0,28 1 34 0276 02 /4 0,67 0,53 0,31 3 34 0276 03 /8 0,75 0,60 0,34 1 34 0276 04 /2 0,81 0,71 0,38 5 34 0276 05 /8 0,94 0,82 0,44 3 34 0276 06 /4 1,03 0,92 0,50 34 0276 08 1 1,16 1,10 0,50 Sealing washer should be ordered separately, see page 9.8.001.09 9.8.001.02 B B E B
