X-On Electronics has gained recognition as a prominent supplier of CU20029-UW1J Vacuum Fluorescent Displays - VFD across the USA, India, Europe, Australia, and various other global locations. CU20029-UW1J Vacuum Fluorescent Displays - VFD are a product manufactured by Noritake. We provide cost-effective solutions for Vacuum Fluorescent Displays - VFD, ensuring timely deliveries around the world.

CU20029-UW1J Noritake

Name: CU20029-UW1J
Brand: Noritake
SKU: CU20029UW1J_Noritake
Availability: InStock
Rating: 5 (11 reviews)

CU20029-UW1J electronic component of Noritake

CU20029-UW1J Vacuum Fluorescent Displays - VFD

Images are for reference only
See Product Specifications

Part No.	CU20029-UW1J
Manufacturer:	Noritake
Category:	Vacuum Fluorescent Displays - VFD
Description:	Vacuum Fluorescent Displays - VFD 2x20 VFD w/ Controller
Datasheet:	CU20029-UW1J Datasheet (PDF)
	Large This product is classified as Large/Heavy, additional shipping charges may apply. A customer service representative may contact you after ordering to confirm exact shipping charges

Price (USD)

1: USD 163.449 ea
Line Total: USD 163.45

Availability - 116
Ship by Wed. 01 Jan to Fri. 03 Jan

MOQ: 1 Multiples: 1
Pack Size: 1

CU20029-UW1J More Buying Options & Price Grid(s)

Please wait...

Availability Price Buy Price Quantity

116

Ship by Wed. 01 Jan to Fri. 03 Jan

MOQ : 1
Multiples : 1

1 : USD 163.449
10 : USD 157.168

6

Ship by Wed. 01 Jan to Fri. 03 Jan

MOQ : 1
Multiples : 1

1 : USD 208.81
10 : USD 207.326

Specifications

Manufacturer

Noritake Noritake

Product Category

Vacuum Fluorescent Displays - VFD Vacuum Fluorescent Displays - VFD

Interface

8/4Bit Parallel 8/4Bit Parallel

Kind Of Display

Alphanumeric Alphanumeric

Colour

Green (Blue - Green) Green (Blue - Green)

Type Of Pin Configuration

1X6, 2X7 1X6, 2X7

Type Of Display

Vfd Vfd

Digit Height

9.2 mm 9.2 mm

Character Width

3.8 mm 3.8 mm

Number Of Characters Columns X Lines

20X2 20X2

Operating Temperature

- 40 To 85 C - 40 To 85 C

Storage Temperature

- 50 To 85 C - 50 To 85 C

Luminosity

350Cd/M² 350Cd/M²

Number Of Pins

20 20

Contacts Pitch

2.54Mm 2.54Mm

Dimensions

146X43x9.4Mm 146X43x9.4Mm

Window Dimensions H X W

130X32mm 130X32mm

Supply Voltage

4.75 To 5.25 VDC 4.75 To 5.25 VDC

Notes:- Show Stocked Products With Similar Attributes.
