VFD Module GU-D series SIMPLIFIED DATASHEET GU128X32D-D903S Features Outline dimensions VF Display Module equips 16 (8x2) Capacitive Touch Switches. Specifications Electrical Ratings Note: Interface level is 3.3V C-MOS. Interface Parameter Symbo Min. Typ. Max. Unit Condition Asynchronous Serial, SPI and I2C (Logic level is 3.3V for all) Power Supply Voltage VCC 4.75 5.00 5.25 VDC Pin Assignment Electrical Characteristic Please refer to a full specification for Characteristics of I/O ort. CN1: Asynchronous Serial Parameter Symbo Min. Typ. Max. Unit Condition Pin No. Signal Pin No. Signal I2C Logic Input Current IIH-1 - - 1.0 uADC VIN=3.3V 1 VCC 8 TXD SDA,SCL,/RESET IIL-1 - - -0.5 mADC VIN=0V 2 RXD 9 /TRDY I2C Logic Input Voltage VIH-1 2.5 - - VDC - 3 GND 10 GND SDA,SCL,/RESET VIL-1 - - 0.6 VDC - 4 MBUSY 11 P00 I2C Logic Output Voltage SDA,SCL VOL-1 - - 0.5 VDC IOL=0.5mA 5 IC 12 P01 I2C Logic Output Voltage VOH-2 2.6 - - VDC IOH=-0.5mA 6 /RESET 13 P02 MBUSY,/TRDY VOL-2 - - 0.5 VDC IOL=0.5mA 7 HBUSY 14 P03 Logic Input Current RxD IIH-2 - - 1.0 uADC VIN=3.3V MOSI,SCK,/CS,HBUSY,/RESET IIL-2 - - -0.5 mADC VIN=0V CN1 : SPI Interface Logic Input Voltage RXD VIH-2 2.5 - - VDC - Pin No. Signal Pin No. Signal MOSI,SCK,/CS,HBUSY,/RESET VIL-2 - - 0.6 VDC - 1 VCC 8 MISO Logic Output Voltage VOH-3 2.6 - - VDC IOH=-0.5mA 2 MOSI 9 /TRDY TXD,MISO,MBUSY,/TRDY VOL-3 - - 0.5 VDC IOL=0.5mA 3 GND 10 GND Power Supply Current ICC-1 - 230 300 mADC All dots turned on 4 MBUSY 11 P00 ICC-2 - 140 180 mADC All dots turned off 5 SCK 12 P01 ICC-3 - 7 9 mADC Display power off 6 /RESET 13 P02 Power consumption - 1.15 1.50 W All dots turned on 7 /CS 14 P03 Optical characteristics CN1 : I2C Interface Parameters Pin No. Signal Pin No. Signal 2 2 Luminance 350 cd/m Min. (700 cd/m Typ.) 1 VCC 8 IC Color of illumination Green (Bluish green) 2 SDA 9 /TRDY 3 GND 10 GND Physical Specification 4 MBUSY 11 P00 Parameters 5 SCL 12 P01 Number of Dots 4,096 (128 x 32) 6 /RESET 13 P02 Active area (XxY) 57.45 mm x 13.93 mm 7 IC 14 P03 Size of Dot (XxY) 0.30 mm x 0.29 mm Pitch of Dot (XxY) 0.45 mm x 0.44 mm Character Fonts Weight approximately 38g Parameters Font tables 5 x 7 Alpha-numeric, Kana, International Environmental Specification 8 x 16 Alpha-numeric, Kana, International Parameters 16 x 16 CJK Operating Temperature -40 ~ +85 degrees Celsius Number of digits & lin 5x7 dot font: 18/21digits x 4 lines Storage Temperature -40 ~ +85 degrees Celsius 16x16 dot font: 8digits x 1line Operating Humidity 20 ~ 80% R.H. (non-condensing) Storage Humidity 20 ~ 80% R.H. (non-condensing) Functions Vibration (non-operating) 10-55-10Hz, all amplitude 1mm, 30 minutes, X-Y-Z Characters and Graphics display, Control command, Shock (non-operating) 392m/s2 (40G) 9ms X-Y-Z, 3 times each direction Macro & P Macro, I/O port, Touch Switch with Calibration, etc. Leaflet contents, and specifications and external appearance of products, may change without notice. Please confirm product details in the specification. (C)Copyright NORITAKE ITRON CORP. 16/03X-ON Electronics Largest Supplier of Electrical and Electronic Components Click to view similar products for Vacuum Fluorescent Displays - VFD category: Click to view products by Noritake manufacturer: Other Similar products are found below : M0220SD-202SDAR1-CWC GU256X64F-9900 GU140X16G-7003B GU140X32F-7003B CU20049-UW2A CU16025-UW6J CU20029- UW1J GU140X32F-7000B VFD2041 VFD2041-VPT VK162-12 VK162-12-E VK202-25 VK204-25 VK204-25-E M0216SD-162SDAR2-1 M0216SD-162SDAR8 M0220MD-202MDAR1-1 M0220MD-202MDAR1-3 CU20025-UW1J CU20045-UW5J CU20049-UW2J CU24063- Y1A CU40025-UW6J GU140X16G-7003 VK202-25-V GU256X128E-3900B M0220SD-202SDAR1-1G GP1184A01A M162MD07AA- 000 VK202-25-V-E
